Fairbanks 6001 Delta Series Analog Platforms User Manual
Page 5
50661
5
12/04 Issue #4
Section 3: Installation
The platforms are shipped ready to interface to an analog indicator. All
models use the same wiring color code.
1. Place the platform where it will be used
2. Level the platform using the feet
3. Connect the Interface cable to the indicator. The loadcell interface
cable is identified as follows:
Platform Termination
Wire Color
Function
TB1-2
Black
(-) Excitation
TB1-1
Green
(+) Excitation
TB1-3
Yellow
Outer Shield-Grd
N/A
Bare
Inner Shield-Chassis Grnd
TB1-4
White
(+) Signal
TB1-5
Red
(-) Signal
