Fairbanks 6001 Delta Series Analog Platforms - Manual (Page 20)

50661 20 12/04 Issue #4
LOAD DIRECTION
D
D
C
B
A
24"
3.750"
1.875"
.50
1.875"
3.010"
3.750"
PART #
22320
CAPACITY
50 LB
"A"
62.5 LB 22004
"B" "C"
.160
.160 .998
.998
.745
.677
"D"
.18
.18
22321 125 LB .745 .250 .984 .18
.18 .720 .998 .190 75 LB 22005
LOADCELL WIRING
(+) SIG
(-) SIG
INPUTS
OUTPUTS
PIN 2
PIN 1
PIN 4
PIN 5
LOADCELL
WHITE
RED
(-) EXC GREEN
(+) EXC BLACK
YELLOW PIN 3 SHIELD
LOADCELL
.50
50661-7
GND
0.180
5 HOLES
Material 2024-13 Aluminum
Rated Output 0.9 mV/V NOMINAL
Matched output Ratio: 0.0009 mV/V/ohm +/- 0.05%
Combined Linearity and Hysterises +/- 0.020%
Non-Repeatability 0.01%
Creep in 20 Min 0.03%
Zero Balance +/- 0.30 mV/V
Data Temp Range +15 to +104 Deg F.
Terminal Resistance
INPUT 1193 +/- 5 ohms
OUTPUT 1000 +/- 5 ohms
INSULATION 5000 Meg Ohms @ 50 VDC MINIMUM
Max Load 213% of Cap without change of Characteristics
