Blagdon Pump AVB75 Metallic - Manual (Page 5)

avbmdl1sm-rev0111 Model AVB Metallic Page 3
Performance Curve, AVB75 Metallic Design Level 1
CAPACITY
Liters per minute
BAR PSI
HEAD
100
80
60
40
20
0 0
1
2
3
4
5
6
7
0 20 40 60 80 100 120 140 160 180 200
900 800 700 600 500 400 300 200 100 0
220 240 260
U.S. Gallons per minute
30
20
25
10
15
5
9.1
6
7.6
3
4.5
1.5
NPSHR
METERS FEET
RS30 Metallic Performance Curve
Performance based on the following: elastomer fitted pump, flooded suction, water at ambient conditions.
The use of other materials and varying hydraulic conditions may result in deviations in excess of 5%.
10(17)
20(34)
30(51)
40(68)
50(85)
60(102)
70(119)
80(136)
90(153)
100 PSI (6.8 Bar)
80 PSI (5.44 Bar)
60 PSI (4.08 Bar)
40 PSI (2.72 Bar)
