Composite parts list – Blagdon Pump AVB75 Metallic User Manual
Page 13

avbmdl1sm-rev0111
Model AVB Metallic Page 11
ITEM
PART NUMBER
DESCRIPTION
qty
1
B031-183-003
Assy - Air Valve (See Exploded View for Details)
1
B031-147-003
Assy - Air Valve, Pulse Output Kit (See Exploded View)
1
2
B032-050-000
Assy - AirVantage (See Exploded View for Details)
1
3
B050-014-354
Check Ball, Santoprene
4
B050-014-360
Check Ball, Nitrile
4
B050-014-364W
Check Ball, EPDM
4
B050-014-365
Check Ball, Neoprene
4
B050-015-600
Check Ball, PTFE
4
4
B070-006-170
Bushing, Intermediate
2
5
B095-110-000
Assy, Pilot Valve (See Exploded View for Details)
1
6
B114-029-157
Assy, Intermediate (See Exploded View for Details)
1
7
B132-035-360
Bumper, Diaphragm
2
8
B135-034-506
Bushing, Plunger
2
9
B165-133-150
Cap, Sensor Mount Plate
2
10
B170-006-115
Cap Screw, Hex Head (3/8-16 x 1 Stainless)
4
B170-006-330
Cap Screw, Hex Head (3/8-16 x 1 Zinc Plated Steel)
4
B171-059-115
Cap Screw, Socket Head (3/8-16 x 2.50 Pulse Output Kit)
B171-059-330
Cap Screw, Socket Head (3/8-16 x 2.50 Pulse Output Kit)
11
B170-055-115
Cap Screw, Hex Head (1/2-13 x 2-1/2 Stainless)
16
B170-055-330
Cap Screw, Hex Head (1/2-13 x 2-1/2 Zinc Plated Steel)
16
12
B170-060-115
Cap Screw, Hex Head (7/16-14 x 2 Stainless)
16
B170-060-330
Cap Screw, Hex Head (7/16-14 x 2 Zinc Plated Steel)
16
13
B170-122-115
Cap Screw, Hex Head (5/16-18 x 5 Stainless)
4
B170-122-330
Cap Screw, Hex Head (5/16-18 x 5 Zinc Plated Steel)
4
14
B171-059-330
Cap Screw, Socket Flat Head (7/16-14 x 1-1/4)
8
15
B171-082-115
Cap Screw, Socket Head (5/16-18 x 1-1/4 Stainless)
4
B171-082-330
Cap Screw, Socket Head (5/16-18 x 1-1/4 Zinc Plated Steel) 4
16
B196-164-010
Chamber, Outer (Cast Iron Units)
2
B196-164-110
Chamber, Outer (Stainless Units)
2
B196-164-112
Chamber, Outer (Alloy-C Units)
2
B196-200-156
Chamber, Outer (Aluminum Units)
2
17
B196-207-156
Chamber, Inner (Right Side)
1
18
B196-208-156
Chamber, Inner (Left Side)
1
19
B286-098-354
Diaphragm, Santoprene
2
B286-098-360
Diaphragm, Nitrile
2
B286-098-363
Diaphragm, FKM
2
B286-098-364
Diaphragm, EPDM
2
B286-098-365
Diaphragm, Neoprene
2
20
B286-098-604
Diaphragm, Teflon Overlay
2
21
B360-093-360
Gasket, Main Air Valve
1
22
B360-104-379
Gasket, Air Inlet Cap
1
23
B360-113-365
Gasket, Inner Chamber
2
24
B360-114-360
Gasket, Pilot Valve
1
25
B518-143-010
Manifold, Suction (Cast Iron Units)
1
B518-143-010E
Manifold, Suction (Cast Iron Units)
1
B518-143-110
Manifold, Suction (Stainless Units)
1
B518-143-110E
Manifold, Suction (Stainless Units)
1
B518-143-112
Manifold, Suction (Alloy-C Units)
1
B518-143-112E
Manifold, Suction (Alloy-C Units)
1
B518-143-156
Manifold, Suction (Aluminum Units)
1
B518-143-156E
Manifold, Suction (Aluminum Units)
1
B518-171-010
Manifold, Suction (Cast Iron ANSI Flanged Units)
1
B518-171-010E
Manifold, Suction (Cast Iron DIN Flanged Units)
1
B518-171-110
Manifold, Suction (Stainless ANSI Flanged Units)
1
ITEM
PART NUMBER
DESCRIPTION
qty
25
B518-171-110E
Manifold, Suction (Stainless DIN Flanged Units)
1
B518-171-156
Manifold, Suction (Aluminum ANSI Flanged Units)
1
B518-171-156E
Manifold, Suction (Aluminum DIN Flanged Units)
1
26
B518-144-010
Manifold, Discharge (Cast Iron Units)
1
B518-144-010E
Manifold, Discharge (Cast Iron Units)
1
B518-144-110
Manifold, Discharge (Stainless Units)
1
B518-144-110E
Manifold, Discharge (Stainless Units)
1
B518-144-112
Manifold, Discharge (Alloy-C Units)
1
B518-144-112E
Manifold, Discharge (Alloy-C Units)
1
B518-144-156
Manifold, Discharge (Aluminum Units)
1
B518-144-156E
Manifold, Discharge (Aluminum Units)
1
B518-172-010
Manifold, Discharge (Cast Iron ANSI Flanged Units)
1
B518-172-010E
Manifold, Discharge (Cast Iron DIN Flanged Units)
1
B518-172-110
Manifold, Discharge (Stainless ANSI Flanged Units)
1
B518-172-110E
Manifold, Discharge (Stainless DIN Flanged Units)
1
B518-172-156
Manifold, Discharge (Aluminum ANSI Flanged Units)
1
B518-172-156E
Manifold, Discharge (Aluminum DIN Flanged Units)
1
27
B530-038-000
Muffler
1
28
B545-007-115
Nut, Hex (7/16-14 Stainless)
16
B545-007-330
Nut, Hex (7/16-14 Zinc Plated Steel)
16
29
B545-008-115
Nut, Hex (1/2-13 Stainless)
16
B545-008-330
Nut, Hex (1/2-13 Zinc Plated Steel)
16
30
B560-001-360
O-ring, Plunger Pin
2
31
B560-011-360
O-ring, Adapter Plate
1
32
B560-033-360
O-ring, Sensor Bushing
2
33
B560-201-360
O-ring, Probe Tip
2
34
B560-203-360
O-ring, Sensor Cap
2
35
B612-232-150
Plate, Inner Diaphragm
2
36
B612-194-010
Plate Assy, Outer Diaphragm (Cast Iron Units)
2
B612-194-110
Plate Assy, Outer Diaphragm (Stainless Units)
2
B612-194-112
Plate Assy, Outer Diaphragm (Hastalloy Units)
2
B612-194-157
Plate Assy, Outer Diaphragm (Aluminum Units)
2
37
B612-229-150
Plate, Air Inlet Adapter
1
38
B620-020-115
Plunger, Actuator
2
39
B675-042-115
Ring, Retaining
2
40
B685-040-120
Rod, Diaphragm
1
41
B720-004-360
Seal, Diaphragm Rod
2
42
B722-090-360
Seat, Buna
4
B722-090-363
Seat, FKM
4
B722-090-364
Seat, EPDM
4
B722-090-365
Seat, Neoprene
4
B722-090-550
Seat, UHMW Polyethylene
4
B722-090-600
Seat, PTFE
4
B722-090-080
Seat, Carbon Steel (must use with seals - item #43)
4
B722-090-110
Seat, Stainless (must use with seals - item #43)
4
B722-090-150
Seat, Aluminum (must use with seals - item #43)
4
43
B560-105-360
Seal, Nitrile O-ring
8
B560-105-363
Seal, FKM O-ring
8
B560-105-364
Seal, EPDM O-ring
8
B560-105-365
Seal, Neoprene O-ring
8
B720-055-608
Seal, Conductive PTFE
8
44
B724-007-000
Sensor Assembly, AirVantage
1
45
B846-001-167
Tip, AirVantage Probe
2
46
B920-027-000
Wire, Patch
1
Composite Parts List
