Composite Repair Parts List
1
B031-183-000
Air Valve Assembly
1
B031-179-000
Air Valve Assembly
1
2
B050-005-354
Ball, Check
4
B050-005-360
Ball, Check
4
B050-005-363
Ball, Check
4
B050-005-364
Ball, Check
4
B050-005-365
Ball, Check
4
B050-010-600
Ball, Check
4
3
B070-006-170
Bushing
2
4
B095-096-000
Pilot Valve Assembly
1
5
B114-024-157
Intermediate, Bracket
1
B114-024-010
Intermediate, Bracket
1
B114-024-110
Internediate, Bracket
1
6
B132-035-360
Bumper, Diaphragm
2
7
B135-034-506
Bushing, Plunger
2
8
B165-118-157E Cap, Air Inlet Assembly 3/4" NPT
1
B165-118-010E Cap, Air Inlet Assembly 3/4" BSP (Parallel) 1
B165-118-110
Cap, Air Inlet Assembly 3/4" NPT
1
9
B170-060-115
Capscrew, Hex Hd 7/16-14 X 2.00
16
B170-060-330
Capscrew, Hex Hd 7/16-14 X 2.00
16
10
B170-061-115
Capscrew, Hex Hd 3/8-16 X 1.75
16
B170-061-330
Capscrew, Hex Hd 3/8-16 X 1.75
16
11
B170-085-115
Capscrew, Hex Hd 5/16-18 X 2.00
4
B170-085-330
Capscrew, Hex Hd 5/16-18 X 2.00
4
12
B170-006-115
Capscrew, Hex Hd 3/8-16 X 1.00
4
B170-006-330
Capscrew, Hex Hd 3/8-16 X 1.00
4
13
B171-059-115
Capscrew, Soc Hd 7/16-14 X 1.25
8
B171-059-330
Capscrew, Soc Hd 7/16-14 X 1.25
8
B171.011.110
Capscrew, Soc Hd 1/2-13 X 1.25
8
(Stainless Steel Only)
14
B196-169-156
Chamber, Outer
2
B196-169-010
Chamber, Outer
2
B196-169-110
Chamber, Outer
2
15
B196-170-156
Chamber, Inner
2
B196-170-010
Chamber, Inner
2
B196-170-110
Chamber, Inner
2
16
B286-103-354
Diaphragm
2
B286-103-360
Diaphragm
2
B286-103-364
Diaphragm
2
B286-103-365
Diaphragm
2
17
B286-103-600
Diaphragm, Overlay
2
ITEM PART NO.
DESCRIPTION
QTY
18
B360-093-360
Gasket, Air Valve
1
19
B360-103-360
Gasket, Pilot Valve
1
20
B360-104-379
Gasket, Air Inlet
1
21
B360-105-360
Gasket, Inner Chamber
2
22
B518-161-010E Manifold, Suction 1½" BSP (Parallel)
1
B518-151-110E Manifold, Suction 1½" BSP
1
Center Ported (Tapered)
B518-161-156E Manifold, Suction 1½" BSP (Parallel)
1
23
B518-162-010E Manifold, Discharge 1½" BSP (Parallel)
1
B518-152-110E Manifold, Discharge 1½" BSP
1
Center Ported (Tapered)
B518-162-156E Manifold, Discharge 1½" BSP (Parallel)
1
24
B530-033-000
Silencer
1
25
B545-005-115
Nut, Hex 3/8-16
16
B545-005-330
Nut, Hex 3/8-16
16
26
B545-007-115
Nut, Hex 7/16-14
16
B545-007-330
Nut, Hex 7/16-14
16
27
B560-001-360
O-Ring
2
28
B560-084-360
Seal (O-Ring)
(see item 34)
8
B560-084-363
Seal (O-Ring)
(see item 34)
8
B560-084-364
Seal (O-Ring)
(see item 34)
8
B720-061-600
Seal
(see item 34)
8
29
B612-039-157
Plate, Outer Diaphragm
2
B612-039-010
Plate, Outer Diaphragm
2
B612-097-110
Plate, Outer Diaphragm
2
30
B612-195-157
Plate, Inner Diaphragm
2
B612-195-082
Plate, Inner Diaphragm
2
31
B620-020-115
Plunger, Actuator
2
32
B675-042-115
Ring, Retaining
2
33
B685-059-120
Rod, Diaphragm
1
34
B720-004-360
Seal, Diaphragm Rod
2
35
B722-091-550
Seat, Check Ball
4
B722-091-080
Seat, Check Ball
4
B722-091-110
Seat, Check Ball
4
B722-091-150
Seat, Check Ball
4
B722-091-600
Seat, Check Ball
4
36
B901-038-115
5/16 Flat Washer
4
B901-038-330
5/16 Flat Washer
4
37
B901-038-115
3/8 Flat Washer
4
B901-048-330
3/8 Flat Washer
4
38
B570-009-363
Pad, Wear (Use With 286-099-363)
2
ITEM PART NO.
DESCRIPTION
QTY
Center-Ported Stainless Steel ONLY.
Center-Ported Stainless Steel ONLY.
Tapered
Tapered
