Page 10
PARTS LIST
REF. PART No. DESCRIPTION QTY
1 06-207 BASE LEG 2
2 D274 SKT C’SUNK SCREW M3 x 10 6
3 G258 O-RING 2
4 06-007 VALVE BLOCK PLUG 2
5 06-097 VALVE BLOCK 1
6 06-005 VALVE CARRIER 1
7 06-004 SLIDE VALVE 1
8 06-003 SLIDE VALVE PLATE 1
9 06-059 PLATE SEAL 1
10 06-002 PORT SEAL 1
11 06-160 CENTRE SECTION 1
12 D215 SKT CAP SCREW M6 x 20 16
13 06-034 SILENCER 1
14 06-139 OUTER COVER 2
15 C048 WASHER M6 8
16 D322 SKT CAP SCREW M4 x 10 4
17 SEE TABLE MANIFOLD 2
18 SEE TABLE O-RING - MANIFOLD 4
19 06-161 BALL CAGE 2
20 SEE TABLE VALVE BALL - DISCHARGE 2
21 06-163 VALVE SEAT - DISCHARGE 2
22 G259 O-RING - VALVE SEAT 2
23 SEE TABLE DIAPHRAGM 2
24 SEE TABLE VALVE BALL - SUCTION 2
25 06-142 VALVE SEAT - SUCTION 2
26 H280 CIRCLIP 2
27 06-132 DIAPHRAGM SHAFT 1
28 06-209 SHAFT LIP SEAL 6
29 06-210 DIAPHRAGM SHAFT BUSH - ‘A’ 2
-
31 G279 O-RING 2
32 06-153 DIAPHRAGM SHAFT BUSH - ‘B’ 2
33 G264 O-RING 2
34 SA10160 FRONTPLATE ASSY 2
35 06-147 DIAPHRAGM SUPPORT 2
36 06-009 BACKPLATE 2
37 06-141 DIAPHRAGM – PTFE 2
REF
No.
DESCRIPTION POLYESTER EPDM VITON QTY
23 DIAPHRAGM 06-010 06-070 06-060 2
ELASTOMER TABLE
SANTOPRENE ®
06-147
REF
No.
DESCRIPTION PTFE VITON STAINLESS
STEEL
QTY
20 VALVE BALL - DISCHARGE 06-145 06-151 06-146 2
24 VALVE BALL - SUCTION 06-108 06-109 06-110 2
ELASTOMER TABLE
23 DIAPHRAGM SEE TABLE - - 2
PTFE
(ONE–PIECE)
-
-
06-174
18 O-RING G256 G336 - - 4
EPDM
G333
- These items are available in a recommended spares kit. Please refer to your local stockist / distributor for details.
- These items are available in a recommended spares kit - ASK0604SS - Air side Kit.
Santoprene is a registered trade name of Monsanto Corp.
PARTS LIST - cont.
REF
No.
PART
NUMBER
DESCRIPTION QTY
THE FOLLOWING PARTS ARE USED ON ATEX CERTIFIED PUMPS (see page 7)
38 SA10289 GROUNDING LEAD ASSY. M6 1
39 SP467 ATEX I/D TAG 1
40 SP472 TIE-LOK TIE 1
REF No. DESCRIPTION END CONNECTION QTY
TRI-CLAMP RJT DIN
17 MANIFOLD SA10417 - - 2
MANIFOLD OPTIONS
BSP
06-167
