PAGE 4
TECHNICAL DATA
FLUID CONNECTIONS
CAPACITY
MAX SOLIDS
MAX DISCHARGE HEAD
DISPLACEMENT/STROKE
DIN 65 TRI-CLAMP SIZE
Other options available (RJT/DIN)
0 - 500 Litres/Minute
(0 - 110 Gallons/Minute)
6 MM
(1/4”)
88 Meters
(289 ft)
1.9 Litres
(0.42 UK Gallons)
MAX. WORKING PRESSURE
AIR INLET
TEMPERATURE LIMITS
PUMP WEIGHTS :-
8.6 Bar (125 psi)
3/4” BSP (F)
Determined by Elastomers
SA :- 60 Kg
SS :- 92 Kg
�
Caution -
Operating temperature limitations are as follows:
Operating Temperatures
Materials
Maximum
Minimum
Optimum
Buna-n -
General purpose, oil resistant. Shows good solvent, oil, water and hydraulic fluid resistance. Should not
be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro hydrocarbons.
176
o
F
80
o
C
-18
o
F
-28
o
C
50
o
to 140
o
F
10
o
to 60
o
C
EPDM -
Shows very good water and chemical resistance. Has poor resistance to oils and solvents, but is fair on
ketones and alcohols.
212
o
F
100
o
C
-11
o
F
-24
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Neoprene -
All purpose. Resistant to vegetable oil. Generally not affected by moderate chemicals, fats greases
and many oils and solvents. Generally attacked by strong oxidising acids, ketones, esters, nitro hydro carbons and
chlorinated aromatic hydrocarbons.
212
o
F
100
o
C
-4
o
F
-20
o
C
50
o
to 130
o
F
10
o
to 54
o
C
Santoprene® -
Injection moulded thermoplastic elastomer with no fabric layer. Long mechanical flex life.
Excellent abrasion resistance.
212
o
F
100
o
C
-10
o
F
-23
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Virgin PTFE -
Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
PTFE : molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine
trifluoride or oxygen difluoride which readily liberate free fluorine at elevated temperatures.
356
o
F
180
o
C
32
o
F
0
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Viton® -
Shows good resistance to a wide range of oils and solvents : especially all alphatic, aromatic and
halogenated hydrocarbons, acids, animal and vegetable oils.
356
o
F
180
o
C
0
o
F
-18
o
C
75
o
to 212
o
F
24
o
to 100
o
C
TYPICAL CODE =
B50 04. S A. B B. E T S - P
WETTED COMPONENTS
S : 316L STAINLESS STEEL
NON - WETTED COMPONENTS
A : ALUMINIUM
S : STAINLESS STEEL
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
MODEL :-
B : STANDARD
X : ATEX CAT. 2
VALVE SEATS
S : 316 STAINLESS STEEL
VALVE BALLS
E : EPDM
S : 316 STAINLESS STEEL
T : PTFE
DIAPHRAGMS
E : EPDM
T : PTFE
O : ONE-PIECE PTFE
DESIGN LEVEL
DESIGN LEVEL
SUFFIX
P : BSP CONNECTIONS
P1: TRI-CLAMP CONNECTIONS
ELECTRO - POLISHED
IDEX Pump Technologies (Ireland) Ltd.,
A Unit of IDEX Corporation,
R79, Shannon, Co Clare, IRELAND.
TEL. : +353 61 471933 FAX. : +353 61 475046
Web Site : www.blagdonpump.com
E-Mail : [email protected]
IMPORTANT
This pump should be used in accordance with the requirements of the Safety, Health & Welfare at Work Act 2005.
All business conducted subject to IDEX Pump Technologies, Ireland. Terms and Conditions of Sale, available on request.
B50 05. S A. B B. E T S - P
