8.4 Replacements
WARNING!!
Verify system power is off before attempting to replace any system
components.
8.4.1 Axis Unit
An axis unit cannot be partially replaced. The entire unit must be replaced with an identical
unit, of the same model and with the same capacity (refer to Chapter 2 - Specifications). Prior
to installation, set the dip switches on the new unit in accordance with the application
requirements.
8.4.2 Tool Unit
The gear, motor, and encoder are assembled as a complete unit. If a problem arises in one
of the components, the entire tool unit should be replaced in order to ensure the highest level
of performance. Verify that the new tool is of the same type as the one being replaced.
8.4.3 Cables
An extra set of cables can be supplied with the AFC1150. The spares could be used to assist
in troubleshooting, or to replace damaged operational cables. If cable replacement is
required, carefully disconnect damaged cable, and re-connect with known good spare. Verify
for proper operation. FEC INC. recommends the use of FEC INC. cable assemblies only, and
will not warranty damage caused from other cable.
