49 62-0390-02
39 Analog
Input
Reserve A No units Present Value R
40 Analog
Input
Reserve B No units Present Value R
41 Analog
Input
Reserve C No units Present Value R
42
2 Analog
Input
External Input 1 Pulse Present Value
43
2 Analog
Input
External Input 2 Pulse Present Value
1. To clear single meter kWh/kVARh, select reset kW/kWh on the display menu of the
meter. This function will also reset external inputs. Jumper J6 must be closed.
2. External inputs are standard on Class 5000 meters and optional on Class 3400
meters (Part of Expanded Feature Package). To clear external inputs, select reset kW/
kWh on the display menu of the meter. This function will also reset kW/kVARh. Jumper
J6 must be closed.
BACnet Object Descriptors: CL3200
Instance
ID
BACnet
Object Description Units
BACnet
Property
CL
3200
