Programming Information

20

AXB-TC and AXB-TCR Television Controllers (& Receivers)

Send_Commands (Cont.)

XCHM
Changes the IR output pattern for
the XCH command.

Syntax:

SEND_COMMAND ,'XCH-'

Variable:

Mode = 0-4

Example:

SEND_COMMAND IR_1,'XCH 3'

Sets the IR_1 device's extended channel command to mode 3.
Mode 0 Example (default): [x] [x]

SEND_COMMAND IR_1, 'XCH 3'

Transmits the IR code as 3-enter.

SEND_COMMAND IR_1, 'XCH 34'

Transmits the IR code as 3-4-enter.

SEND_COMMAND IR_1, 'XCH 343'

Transmits the IR code as 3-4-3-enter.
Mode 1 Example:

SEND_COMMAND IR_1, 'XCH 3'

Transmits the IR code as 0-0-3-enter.

SEND_COMMAND IR_1, 'XCH 34'

Transmits the IR code as 0-3-4-enter.

SEND_COMMAND IR_1, 'XCH 343'

Transmits the IR code as 3-4-3-enter.
Mode 2 Example:

SEND_COMMAND IR_1, 'XCH 3'

Transmits the IR code as 0-0-3.

SEND_COMMAND IR_1, 'XCH 34'

Transmits the IR code as 0-3-4.

SEND_COMMAND IR_1, 'XCH 343'

Transmits the IR code as 3-4-3.
Mode 3 Example: [[100][100]…]

SEND_COMMAND IR_1, 'XCH 3'

Transmits the IR code as 0-3.

SEND_COMMAND IR_1, 'XCH 34'

Transmits the IR code as 3-4.

SEND_COMMAND IR_1, 'XCH 343'

Transmits the IR code as 100-100-100-4-3.

XCH

Transmit the IR code in the format set with the XCHM mode command.
Syntax:

SEND_COMMAND ,'XCH '

Variable:

= 0 through 999
