1. Introduction
The 8800P is a portable, hand-held, microprocessor controlled, battery operated dew-
point meter with built in dry-storage for the sensor. The instrument is ideally suited for all
applications, where quick and precise measurements are required.
Standard Equipment:
1. 8800P Portable Instrument with
sensor, desiccant cartridge and
lithium battery.
2. 2 VCO to Swagelok fittings and 2
Swagelok to barbed hose fittings.
3. Calibration bulb.
4. Shoulder strap.
Optional Equipment:
5. VCO to VCO Fittings.
6. Pig tail.
7. Flexible stainless steel hose.
8. Pressure regulator, all stainless
steel, (preset at 1.5 atm) with
mounting bracket.
9. Coalescing filter, all stainless steel
with mounting bracket.(not shown)
10. Wall transformer (with factory
installed I/O option).
11. Replacement desiccant cartridge.
12. Padded transport case.
3
4
2
1
8 6
5
7
10
11
2
3
12
