iii Teledyne Analytical Instruments
P P P P Per er er er ercent Oxyg cent Oxyg cent Oxyg cent Oxyg cent Oxygen en en en en T T T T Transmitter ransmitter ransmitter ransmitter ransmitter
Table of Contents
1 Introduction
1.1 General .......................................................................... 1-1
1.2 Features ......................................................................... 1-1
1.3 Typical Applications ....................................................... 1-2
2 Operational Theory
2.1 Transmitter Description .................................................... 2-1
2.2 Sensor Description .......................................................... 2-1
2.3 Circuit Description ......................................................... 2-2
2.4 RFI Protection ................................................................ 2-3
3 Operation
3.1 Installation...................................................................... 3-1
3.1.1 System Power Requirements ................................. 3-1
3.1.2 Transmitter ............................................................. 3-1
3.1.3 Junction Box .......................................................... 3-1
3.2 Calibration ..................................................................... 3-2
3.2.1 Installing the Milliammeter ..................................... 3-2
3.2.2 Setting the Electronic Zero (P2) ............................. 3-3
3.2.3 Setting the Span Pot (P1) ....................................... 3-3
3.3 Operating The Oxygen Transmitter ................................. 3-3
4 Maintenance
4.1 Routine Maintenance ..................................................... 4-1
4.2 Cell Replacement .......................................................... 4-1
4.3 Cell Warranty ................................................................. 4-2
Appendix
Specifications ........................................................................ A-1
Recommended Spare Parts List ............................................ A-2
Drawing List ........................................................................... A-2
