CFIP Lumina Tx power
Standard/High Tx Power, dBm
Modulation
6, 7, 8 GHz
10, 11, 13, 15 GHz
17 GHz
4,5
18, 23, 26 GHz
24 GHz
4,5,6
38 GHz
4QAM
+19 / +27
+19 / +25
-25…+5
+19
-20…0
+17
16QAM
+18 / +26
+18 / +24
-25…+4
+18
-20…-1
+16
32QAM
+17 / +25
+17 / +23
-25…+3
+17
-20…-2
+15
64QAM
+15 / +23
+15 / +21
-25…+1
+15
-20…-4
+13
128QAM
+15 / +23
+15 / +21
-25…+1
+15
-20…-4
+13
256QAM
+12 / +20
+12 / +18
-25…-2
+12
-20…-7
+10
CFIP Lumina Labeling
The label can be found on the front side of the unit.
The label contains the following information (see sample in the picture below):
-
Model name (“CFIP Lumina”).
-
Product Number (I18GLT02HB).
-
Unit Serial Number (3203001 00002); serial number uniquely identifies the FODU.
4
For non-degraded Rx sensitivity refer to Technical Description (TD) for maximum Tx level according to Rx level observed.
5
Tx power should not exceed EIRP limitation. Please consult the local spectrum regulating authority.
6
Output Tx range may differ for previous hardware and software versions.
