SAF Tehnika CFIP Lumina FODU ETSI V1.10d - Manual (Page 2)

© SAF Tehnika JSC
Ver. 1.10, 2012
CFIP Lumina series
Microwave Radio Systems
1 According to ETSI channel plan
2 Forward Error Correction (FEC) can be optimized either for sensitivity (Strong FEC) or for capacity (Weak FEC)
3 Higher capacity is available in 16QAM and 4QAM if using 32QAM-256QAM with ACM enabled
4 For non-degraded Rx sensitivity refer to Technical Description (TD) for maximum Tx level according to Rx level observed.
III CFIP Lumina Rx sensitivity, payload capacity
Bandwidth 1 ,
MHz
Modulation FEC 2 6 GHz 7 GHz 8 GHz 10 GHz 11 GHz 13 GHz 15 GHz
17 4 /18
GHz
23 GHz
24 4
GHz
26 GHz 38 GHz
Capacities,
Mbps
4QAM Strong -90.5 -89.5 -89 -88.5 -89.5 -89.5 -89 -90 -89 -89 -91.5 -85 35
16QAM Strong -84.5 -83 -83 -82.5 -83.5 -83.5 -83 -84 -83 -83 -85 -79 69
32QAM Strong -81.5 -80 -80 -80 -80.5 -80.5 -80.5 -80.5 -80 -80 -82 -76 88
64QAM Strong -79 -77.5 -77.5 -77 -78 -77.5 -77 -78 -77.5 -77.5 -79.5 -73.5 115
128QAM Strong -75.5 -74.5 -74 -73.5 -74.5 -74.5 -74 -75.5 -74 -74 -76.5 -70 139
Strong -72.5 -71 -70.5 -70.5 -71 -71 -70.5 -72 -71 -71 -73 -67 162
28
256QAM
Weak -69 -67 -66 -66 -67 -67 -66.5 -69 -67.5 -67.5 -70 -63.5 175
4QAM Strong -89 -87.5 -88 -87.5 -88 -88 -88 -88 -87.5 -87.5 -89.5 -83.5 50
16QAM Strong -82.5 -81.5 -81.5 -81 -82 -82 -81.5 -82.5 -81 -81 -83.5 -77 98
32QAM Strong -80 -78.5 -79 -78.5 -79.5 -79.5 -79 -79.5 -78.5 -78.5 -80.5 -74.5 127
64QAM Strong -77 -76 -75.5 -75.5 -76.5 -76 -76 -77 -75.5 -75.5 -78 -71.5 164
128QAM Strong -74 -73 -72.5 -72.5 -73.5 -73 -72.5 -73.5 -72.5 -72.5 -74.5 -68.5 196
Strong -70.5 -69.5 -69 -68.5 -69.5 -69.5 -69 -70.5 -69 -69 -71 -65 229
40
256QAM
Weak -68 -67 -64.5 -64.5 -65.5 -65 -65 -67.5 -66.5 -66.5 -68.5 -62.5 245
4QAM Strong -87 -85.5 -86 -85.5 -87 -86.5 -86 -87 -85.5 -85.5 -88 -81.5 72/67 3
16QAM Strong -81 -80 -79.5 -79.5 -80.5 -80 -79.5 -80.5 -79.5 -79.5 -82 -75.5 145/135 3
32QAM Strong -78 -77 -77.5 -77 -78 -77.5 -77 -77.5 -76.5 -76.5 -79 -72.5 186
64QAM Strong -75.5 -74.5 -74 -73.5 -74.5 -74.5 -74 -75.5 -74 -74 -76 -70 241
128QAM Strong -72 -71 -71 -70.5 -71.5 -71.5 -71 -72 -70.5 -70.5 -73 -66.5 289
Strong -68.5 -67.5 -67 -66.5 -68 -67.5 -67 -68.5 -67 -67 -69.5 -63 337
56
256QAM
Weak -64 -63 -63 -62.5 -63.5 -63 -62.5 -64.5 -62.5 -62.5 -65 -58.5 366
