15
No. Code Description
1 CN2 Top: PS/2 mouse port
Bottom: PS/2 keyboard port
2 COM1 Serial port
3 LPT1 Parallel/printer port
4 VGA1 Monitor port
5 SW1 UID switch
6 — Gigabit LAN ports
7 — USB 2.0 ports
8 DIMMA1
DIMMA2
DIMMB1
DIMMB2 Branch 0 FBD slots
9 DIMMC1
DIMMC2
DIMMD1
DIMMD2 Branch 1 FBD slots
10 FAN_R2 System fan 2 cable connector
11 FAN_R1 System fan 1 cable connector
12 ATX1 24-pin ATX power connector
13 ATX3 8-pin ATX power connector
14 FAN_CPU1 Processor 1 HSF cable connector
15 U47 Intel 5000P MCH (north bridge)
16 CPU 1 Processor 1 socket
17 U108 Winbond W83792D hardware monitoring IC
18 CPU 2 Processor 2 socket
19 FAN_CPU2 Processor 2 HSF cable connector
