The cradle – Asus MyPal A620BT User Manual
Page 10
1-6
Chapter 1
The cradle
The cradle has three connectors.
•
Device connector - holds the device in place. This is a 26-pin connector
that matches the connector on the bottom of the device.
•
USB connector - synchronizes the device with your PC.
NOTE
The USB cable/connector is not detachable from the back of
the cradle.
•
Power connector - connects the bundled AC adapter. This connector is
located at the back side of the cradle.
Device connector
USB connector
Power connector
