White PaPer
Figure 6. QConvergeConsole Plug-in Network Connectivity Maps
Complete Adapter Management
the QCC Plug-in enables comprehensive management of all aspects and functions of the QLogic Fibre Channel, Converged Network, and intelligent ethernet
adapters in a VMware vSphere environment. Capabilities such as the ability to deploy firmware updates remotely, full integration into VMware Update
Manager (VUM), and an array of diagnostics allow for a powerful yet intuitive interface while lowering administration costs.
Complete Adapter Management
QCC Plug-in
System-wide Firmware Updates
ü
integrated Diagnostics
ü
adapter Parameter tuning
ü
Boot from SaN Configuration
ü
transceiver (SFP+) health information
ü
Figure 7. QConvergeConsole Plug-in with Integrated Diagnostics
