White PaPer
Figure 4. QConvergeConsole Plug-in Mouse Overs Provide Key Information
Network Connectivity Visualization
the QCC Plug-in can instantly display how a QLogic 10Gbe networking adapter and ports are related to VMs, as well as the VMware vSwitch/dvSwitch and
port group to which they are connected. QCC gives an instantaneous view of the relationships in the network. in addition, a mouse-over feature provides
key configuration information for each of the hardware components throughout the network internal to the VMware vSphere server.
PortGroup
vSwitch
QLogic Adapter
VM
Network Connectivity Visualization
with QConvergeConsole
Figure 5. QConvergeConsole Plug-in Network Connectivity Maps
Network Connectivity Visualization
QCC Plug-in
end-to-end Visual representation
ü
health Status Using Color Coding
ü
Mouse Overs Provide Key Device attributes
ü
VLaN and Port Group information
ь
