9. 9V TERMINAL AND REMOTE TEST & HUSH

Smoke alarm with Remote Test & Hush card

Remote Test & Hush Plate

The Remote Test & Hush Plate can be mounted in an easy to reach location to
provide convenient access to the Test and Hush functions of your Models
3000, 5000, 5800, 5800RL, LANSD240P and LANSD240I smoke alarm.

Connection diagram between smoke alarm and Remote Test & Hush Plate
