Table 2. Activity LEDs
LED Indicator Color Activity Description
A. Gigabit Ports
100M Link Green ON A valid 100 Mbps link is established.
Blinking Possible data error, see Troubleshooting
section (AsantéQ).
1G Link Green ON A valid 100 Mbps link is established.
Blinking Possible data error, see Troubleshooting
section (AsantéQ).
ACT Green Blinking Packet activity: transmission or
reception.
FDX/HDX Green ON Operating in full-duplex mode.
OFF Operating in half-duplex mode.
B. 10/100 Ports
LNK/SPD Green ON A valid 100 Mbps link speed is
established.
Yellow ON A valid 10 Mbps link speed is
established.
DPX/ACT Green ON Operating in full-duplex mode.
Green Blinking Activity in full-duplex Mode.
Yellow ON Operating in half-duplex mode.
Yellow Blinking Activity in half-duplex mode.
