PSI On-Grid Series
PROLiNK Solar System
• 1.5KW/2KW/3KW/5KW & 3-phase 10KW on-grid PV inverter
• Advanced DSP control technology delivers accurate data
• Smart MPPTs to enhance overall efficiency
• Modulized design for easy maintenance
• Industrial-grade components used for robust operation
• Data log up to 15 years
• IP 65 protection for outdoor and harsh environment
• Comprehensive LCD monitor for easy-reading
• Free monitoring software
All specifications, designs and contents are subjected to changes without prior notice.
Full Specifications
AMNETZ 1500
AMNETZ 2000
AMNETZ 3000
500VDC
150 ~ 500VDC
370VDC 600VDC 360VDC
116/ 150VDC 125/ 150VDC
11A 10A 16A 17A
250/ 250VDC
Maximum DC Power
Maximum DC Voltage
MPP Voltage Range
Nominal DC Voltage
Start-up Voltage/ Initial Feeding Voltage
Maximum Input Current/ Per String
Capacity
Phase
Maximum Efficiency
DC Reverse-Polarity Protection
Ground Fault Monitoring
INPUT (DC)
MODELS
1500W
AMNETZ 1500
2000W
AMNETZ 2000
3000W
1 Phase-In 1 Phase-Out
>0.99
3 Phase-In 3 Phase-Out
AMNETZ 3000
5000W
AMNETZ 5000
10000W
1650W 2200W 3200W 5300W 11000W
450VDC 500VDC 500VDC 900VDC
230VAC 230VAC 230VAC 3/ N/ PE, 230/ 400VAC
6.6A 8.7A 21.7A 14.5A
150 ~ 400VDC 200 ~ 450VDC 320 ~ 800VDC
AMNETZ 10K
OUTPUT (AC)
EFFICIENCY
COMPLIANCE
ENVIRONMENT
INTERFACE
PHYSICAL
Intelligent Slot
PROTECTION
AC Short Circuit Protection
Grid Monitoring
Dimension (mm) D x W × H
Net Weight (kgs)
230VAC
-20% ~ +15%
50Hz / 60Hz
13A
Nominal AC Voltage
AC Voltage Range
AC Grid Frequency
Nominal Output Current
Power Factor
96.0% 96.5% 98.0%
Yes
Yes
Yes
Yes
160 x 270 x 450 182 x 308 x 515 171.2 x 503.5 x 653.3 136.5 x 268.5 x 410
20 40 11.5 15
USB Card/ Optional: SNMP, RS-232, AS-400 and GPRS Cards
Operating Temperature
Humidity
-25 ~ 55°C -25 ~ 60°C -25 ~ 60°C
0 ~ 100% Relative Humidity (Non-condesing)
Altitude 0 ~ 1000m (Power derating 1% every 100m when altitude is over 1000m)
CE, VDE 0126-1-1, IEC62109, ENEL Guide 2009, RD 1663, G83/ 1-1, AS3100/ AS4777 Standard
PSI On-Grid Series can operate at their optimum power output voltage even under variety of weather conditions. Amnetz PV
inverters also allow a wide input voltage range to generate maximum 96% efficiency. Besides, it also offers user-friendly
design and modulated electric design. Bundled with monitoring software, Amnetz PV inverters can monitor and calculate the
accurate saving energy.
38
