Solar
PCC Series
PROLiNK Solar System
• Intelligent Maximum Power Point Tracking technology
• Built-in DSP controller with high performance
• Automatic battery voltage detection
• Three-stage charging optimizes battery performance
• Auto load-detection
• Multifunction LCD displays detailed information
• Reverse polarity protection of solar panel and battery
• Overcharge and overload protection
• IP 43 protection for outdoor and harsh environment
#1
• IP 21 protection
#2
• Suitable for battery types of sealed lead acid, vented Gel, and NiCd
• Standard RJ45 port or optional RS-485 communication port
for remote monitoring
#1 Only applicable to Model with 50~300W. #2 Only applicable to Model with 3000W.
All specifications, designs and contents are subjected to changes without prior notice.
Full Specifications
75V 150VDC 50V
18A 45A
30 ~ 66V @ 24V 60 ~ 132VDC 15 ~ 33V @ 12V MPPT Range @ Operating Voltage
Maximum PV Array Open Circuit Voltage
Maximum Current
Capacity
>110%: Audiable Alarm Yes Overload Protection
Overcharge Protection
Polarity Reversal Protection @ Solar Cell & Battery
INPUT
MODELS
600W
PCC600
3000W
PCC3000
300W
PCC300
OUTPUT
PROTECTIONS
ENVIRONMENT
PHYSICAL
INDICATION
LCD Panel
LED Display
Sealed Lead Acid, Vented, Gel, MiCd Battery
<±1V
Three Stages: Bulk, Absorption & Floating
25A 60A
97.8%
Three indiators: Solar, Charging & Load Status
Three indiators: Solar, Battery &
Wiring Fault
98%
IP43 IP21
Connected Battery Type
Maximum Charging Current
Ripple Voltage
Maximum Efficiency
Stanby Power Consumption
Charging Method
Yes
Yes
LCD Panel indicating Solar Power, Output Power, Battery Voltage, Charging Current, and Fault Conditions
24V 48V 12V
1W 2W
Nominal Battery Voltage
220 x 170 x 57.5
Input or Output Terminal Block
180 x 210 x 80 135 x 170 x 57.5
1.28 0.92
0~90% Relative Humidity (non-condensing)
-20°C to 55°C
-40°C to 75°C
0 ~ 3000m
Humidity
Operating Temperature
Storage Temperature
Altitude
1.85
Dimension (mm) D x W × H
Net Weight (kgs)
Connector
Type of Mechanical Protection
PCC600 PCC3000 PCC300
PCC Series is a combination of MPPT technology and DSP controller system, it will convert best voltage to charge battery
based on varied temperature. Compared to traditional solar charger controller, it allows your solar panels to operate at their
optimum power output voltage, providing higher efficiency up to 97.7% with lower power loss.
PCC Series with inverter, solar panel, and external battery packs; it will become a standalone solar power system to generate
green power for your home application. PCC Series will convert solar power to charge external batteries, and then provide
power to home appliances via inverter. It’s compatible to 4 different battery types, sealed lead acid, vented, gel and NiCd.
