3. Hardware Installations
EN 4
Step 1. Plug the PPL1500P into the electrical socket and power on the electrical socket.
The Power LED on PPL1500P shall illuminate.
Step 2. Connect the PPL1500P to the ADSL modem, Cable modem or Fiber Optic router with the
Ethernet Network cable (RJ-45) provided.
Step 3. Connect the PPL1500P to the PC / Internet TV / Set-Top Box / Media Player / Blu-Ray Player /
Network Access Storage(NAS) / IP Camera / Gaming Console with the Ethernet Network cable
(RJ-45) provided.
Note 1. Network connection shall establish and active when the Powerline and Ethernet LEDs
are both illuminated.
2. If you have set Network password on your other Powerline adapter, press the PPL1500P
Secure button for 2 seconds. Then press the Secure button on other Powerline adapter in
your network for 2 seconds. Both buttons must be pressed within 2 minutes.
ROOM 1
SECURE
ROOM 2
2
Minutes
2 seconds
Within 2 Minutes
2 seconds
SECURE
600 Mbps
600 Mbps
