Poweramp CentraAir AIR POWERED - Manual (Page 13)

11 4111-0034 — July. 2012
Aug. 2012
INSTALLATION
A— Distance (Leveler Frame
Height)
B— Shim Locations (Under
Rear Vertical Supports)
C— Shim Location (Under
Lip Keepers)
D— Shim Locations (Under
Maintenance Prop)
E— Shim Locations (Under
Lip Spring)
F— Dock Floor
G— Rear Pit Curb Angle
H— String
I— Rear Hinge Frame Angle
J— Distance (Dock Floor-to-
Pit Floor)
K— Dock Leveler Frame
M — Pyramid (Preferred)
N— Stepped (Acceptable)
O— Offset (Not Acceptable)
P — Straight (Not Acceptable)
Q— Removable Frame Section
R— Shim Location (Bellows
Mounting Plate, Both
sides)
Install Dock Leveler
M
N
O
P
Shim
Stacking Methods
C
D
Q
G
B
I
K
H F
J A
R
E
