36 4111-0012 — Aug 2012
April 2013
AR = As Required
NOTE: Brush or track can be purchased separately as replacement parts. Contact factory for part numbers.
Kits provide all parts / hardware to add Toe Guards or Weather Seal to an existing dock leveler.
Weatherseal channel must be welded to leveler
*Note, see Safety section (P.4). Pay special attention to removing grounds to motor anc control box before welding.
Toe Guard / Weather Seal Options
* Provide dock leveler serial number and size of platform when calling or faxing orders .
A
B
C CC
E
E
F
G
H
J
K
