1.7.2 DVI-SPLITPRO-2B I/O Connectors
Connectors Video Source
Input
Connectors
DVI-IN 1
DVI
VGA
(DVI to VGA Adapter)
Component (YPbPr)
(DVI to VGA Adapter and VGA to Component
Adapter)
1 x DVI
1 x VGA
(DVI to DVI/VGA Y Cable)
1 x DVI
1 x Component
(DVI to DVI/VGA Y Cable and VGA to Component
Adapter)
DVI-IN 2 VGA
Composite Composite with a RCA Cable
Output
Connectors
Display
DVI-I OUT
DVI Display
VGA Display
(DVI to VGA Adapter)
1 x DVI Display
1 x VGA Display
(DVI to DVI/VGA Y Cable)
