NXA-WAP200G (FG2255-01)

DIMENSIONS (HWD)

• Antenna fully lowered: 1.34" x 5.04" x 4.29"

(34mm x 128mm x 109mm)

• Antenna fully raised: 3.94" x 5.04" x 4.29"

(100mm x 128mm x 109mm)

WEIGHT

• 0.53lbs (0.24kg)

POWER

• 5.4V

RADIO SPECIFICATIONS

• WLAN standards:

- IEEE 802.11/11b Industry standards
- IEEE 802.11g draft standards

• Media Access Protocal

- IEEE 802.11

• Frequency

- 2.4 - 2.4835 GHz (Industrial Scientific Medical Band)

• Operating Channels

- 11b Mode:

11 Channels (USA, Canada)
13 Channels (Europe)
14 Channels (Japan)

- 11g Mode:

11 Channels (USA, Canada)
13 Channels (Europe, Japan)

• Data Rate Shifting

- 1, 2, 5.5, 6, 9, 11, 12, 24, 36, 48, 54 Mbps

• Modulation Technique

- CCK for 11b mode (1, 2, 5.5, 11 Mbps)
- OFDM for 11g mode (6, 9, 12, 24, 36, 48, 54 Mbps)

• Security

- 64-bit & 128-bit WEP Encryption
- 64-bit & 128-bit WPA Encryption
- 802.1x Pass Through

• Outdoor Power

- 15 dBm @ 11M CCK
- 10 dBm @ 54M OFDM

• Coverage Area

- Indoor: 100ft (30.5m)
- Outdoor: 1000ft (305m)

FIRMWARE/SOFTWARE SPECIFICATIONS

• Management/Configuration

- Built-in browser-based utility with

User Name/Password authentication

• Firmware Upgrade

- TFTP

• IP Connection

- Static IP or DHCP client

• Protocols

- Transparent to layer 3 protocols, such as PPoE and VPN

FRONT COMPONENTS

• LEDs

- Three blue activity and status LED indicators
Power - Indicates power is on
WLAN - Indicates wireless network activity
LAN - Indicates wired LAN activity

REAR COMPONENTS

• Power Connector

- AC Adapter connects to a 1.5A @ 5.4VDC external

power adapter

- Power Over Ethernet (PoE) powers the device through

the CAT5 cable. Both Power and Data can be
transmitted simultaneous through the CAT5 cable.

• Reset Button

- Pressing this button restores the settings to their

factory values: administrator password, IP address,
and other configurations. This button is also helpful if
you cannot access the configuration utility.

- Note: Resetting the WAP will erase all your settings

(WEP Encryption, Wireless and LAN settings,
Passwords, etc.) and restore them to their factory
default values. Do not reset the WAP if you want to
retain these settings.

• LAN Port

The NXA-WAP200G can operate as a Wireless Access Point
or as a Bridge.
- LAN - PC toggle switch
- When configured as a Wireless Access Point it allows

multiple computers to connect to the LAN wirelessly

- When configured as a Bridge is allows devices with a

10/100 port, to be connected to the wireless LAN,
such devices include desktop computers, printers, XBoxes,
PlayStation2s, PVRs, Stereos, etc.

- When the NXA-WAP200G is used as a Wireless

Access Point the switch should be positioned to LAN

- When it is used as a Bridge it should be positioned to PC

• Antenna Connector

- Single 3 dBi external antenna with reversed SMA

connector

ENVIRONMENTAL SPECIFICATION

• Operating Temperature: 0ªC (32ªF) to 50ªC (122ªF)
• Storage Temperature -25ªC (-13ªF) to 70ªC (158ªF)
• Relative Humidity: 10% to 90% non-condensing

CERTIFICATIONS

• FCC, IC, CE, TELEC
• Wi-Fi Interoperable

INCLUDED ACCESSORIES

• One power supply
• Five international plug adapters

OPTIONAL ACCESSORIES

• NXA-WAP2403A (FG2255-20) 3 dBi Ceiling Mount

Omnidirectional Antenna

• CC-NET (FG10-051-10) Ethernet Cable
• CC-NET (FG10-051-10) Ethernet Cable
• NXA-WAP2405A (FG2255-21) 5 dBi Rack/Ceiling Mount

Omnidirectional Antenna

• CC-NET (FG10-051-10) Ethernet Cable
• NXA-WAP2410A (FG2255-23) 10 dBi Yagi Outdoor Directional

Antenna

• NXA-WAP2413A (FG2255-22) 13 dBi Indoor/Outdoor

Directional Antenna

• NXA-WAP2413AMB (FG2255-24) NXA-WAP2413A Mounting Bracket
• NXA-WAP2413ACMB (FG2255-25) NXA-WAP2413A Corner

Mounting Bracket

• NXA-WAP10C (FG2255-26) 10' RG58 Plenum Antenna

Extension Cable
