ACS1208A / ACS1216A User Manual

Hardware Requirements

Console

A VGA, SVGA, or Multisync monitor capable of the highest resolution

that you will be using on any computer in the installation.

A PS/2 style mouse
A PS/2 style keyboard

Computers

The following equipment must be installed on each computer:

A VGA, SVGA or Multisync card.
A 6-pin mini-DIN (PS/2 style) mouse port.
A 6-pin mini-DIN (PS/2 Style) keyboard port.

Cables

Substandard cables may damage the connected devices or degrade overall
performance. For optimum signal integrity and to simplify the layout, we
strongly recommend that you use the high quality CS Custom Cable sets
described below:

Function

CS Part Number

KVM Switch to KVM Switch (Daisy-chaining)

2L-1700

–

0.6 m

2L-1701

–

1.8 m

KVM Switch to Computer

2L-5201P

–

1.2 m

2L-5202P

–

1.8 m

2L-5203P

–

3.0 m

2L-5206P

–

6.0 m
