Acer 420 series - Manual (Page 64)

Appendix A Specifications 56
En
glish
• Ergonomically-centered touchpad pointing device with 4-way
scroll button
I/O ports
• One type II CardBus PC Card slots
• One RJ-45 jack (Ethernet 10/100)
• One RJ-11 jack (V.90/56Kbps)
• One DC-in jack
• One parallel port (ECP/EPP)
• One external monitor port
• One headphone/speaker/line-out jack (3.5mm mini jack)
• One microphone/line-in jack (3.5mm mini jack)
• Three USB ports
• One IEEE 1394 port
• One S-video TV-out (NTSC/PAL) port
• 100-pin port replicator connector for Acer EasyPort
• One SD/MMC slot
• One memory stick slot
Weight and dimensions
• 327(W) x 269(D) x 35.9 (H) mm; (12.9" x 10.6" x 1.4") for 14.1"/
15.0" LCD
• 2.86 kg (6.3lbs) for 14.1" LCD model / 2.99kg (6.6lbs) for 15.0" LCD
model
Environment
• Temperature
• Operating: 5°C ~ 35°C
• Non-operating: -20°C ~ 65°C
• Humidity (non-condensing)
• Operating: 20% ~ 80% RH
• Non-operating: 20% ~ 80% RH
TM420-e.book Page 56 Thursday, August 22, 2002 10:00 AM
