-6- FORM NO. 70935A Nilfi sk ALTO Operator's Manual - SCRUBTEC 770 / 784 / 795
SPECIFICATIONS:
Model Scrubtec 795L Scrubtec 784L Scrubtec 770L
Model Number 05231F 05221F 05211F
Motor, Vac 1 HP (.74kw) three 1HP (.74kw) three 1HP (.74kw) three
stage tangential stage tagential stage tagential
discharge discharge discharge
Power Supply 36 volt (6-6V batteries) 36 volt (6-6V batteries) 36 volt (6-6V batteries)
242AH, 310AH 2420AH, 310AH 242AH, 310AH
Solution Tank 30 gallon (114 liter) 30 gallon (114 liter) 30 gallon (114 liter)
Recovery Tank 30 gallon (114 liter) 30 gallon (114 liter) 30 gallon (114 liter)
Motors, Brush (2) 1 hp PM (.74kw) 1 hp PM (.74kw) 1 hp PM (.74kw)
Motor Traction .50 hp PM (.37kw) .50 hp PM (.37kw) .50 hp PM (.37kw)
Brushes (2) 19 inch (48cm) 17 inch (43cm) 14 inch (36cm)
w/.5” (1.5cm) overlap w/.5” (1.5 cm) overlap w/.5” (1.5 cm) overlap
Brush Speed 200 rpm 200 rpm 200 rpm
Brush Pressure Variable 140 lbs. - 220 lbs. Variable 140 lbs. - 220 lbs. Variable 140 lbs. - 220 lbs.
Speed, Forward Variable to 230 ft./min. Variable to 230 ft./min. Variable to 230 ft./min.
Speed, Reverse Variable to 180 ft./min. Variable to 180 ft./min. Variable to 180 ft./min.
Charger 36V, 21A, 115V/60hz 36V, 21A, 115V/60hz 36V, 21A, 115V/60hz
Length 68.28 inches (173 cm) 67 inches (170 cm) 65.0 inches (165 cm)
Width - Machine 40.33 inches (102 cm) 35.70 inches (91 cm) 30.0 inches (76 cm)
Height 43.75 inches (112cm) 43.75 inches (112 cm) 43.75 inches (112 cm)
Cleaning Rate 42,000 sq ft/hr 35,000 sq ft/hr 29,700 sq ft./hr
(3,901 sq. m/hr) (3,252 sq. m/hr) (2,750 sq ft./hr)
Cleaning Swath 38 inch (97 cm) 33 inch (84 cm) 28 inch (71 cm)
Grade Cleaning 6° Incline 6° Incline 6° Incline
Weight w/Batteries
(310AH) 1025 lbs. 465kg 1015 lbs. 460kg 1005 lbs. 456kg
Shipping Weight
w/batteries (310AH) 1328 lbs. 602kg 1318 lbs. 598kg 1308 lbs. 593kg
Noise 76.5 dBA 76.5 dBA 76.5 dBA
Vibration <2.5 m/s2 <2.5 m/s2 <2.5 m/s2
