16
Calibration kits
Error correction requires that the systematic errors in the measurement
system be characterized by measuring known devices (standards) over the
frequency range of interest with the process of calibration. All calibration kits
contain standards used for this purpose. The standards in the 3.5 mm, 2.4 mm
and Type-N calibration kits use the precision slotless connector (PSC-3.5,
PSC-2.4 and PSC-N). Unless otherwise noted all coaxial calibration kits include
connector gauges and a torque wrench.
Mechanical Connector Frequency Description
calibration type range
kit (GHz)
85050B 7 mm 0.045 - 18 Contains open and short circuits, fixed and sliding terminations.
85050C 7 mm 0.045 - 18 Precision kit. Contains standards for TRL calibration, including precision airline.
Also contains open and short circuits and fixed termination.
85050D 7 mm 0.045 - 18 Economy kit. Contains open and short circuits and precision fixed termination.
Gauges not included.
85052B 3.5 mm 0.045 - 26.5 Contains open and short circuits, fixed and sliding terminations and in-series
adapters.
85052C 3.5 mm 0.045 - 26.5 Precision kit. Contains standards for TRL calibration, including precision airlines.
Also contains open and short circuits, fixed terminations and in-series adapters.
Gauges not included.
85052D 3.5 mm 0.045 - 26.5 Economy kit. Contains open and short circuits, precision fixed termination, and in-series
adapters. Gauges not included.
85054B Type-N 0.045 - 18 Contains open and short circuits, fixed and sliding terminations, in-series adapters
and 7 mm-to-Type-N adapters.
85054D Type-N 0.045 - 18 Economy kit. Contains open and short circuits, fixed terminations, in-series
adapters and 7 mm-to-Type-N adapters. Gauges not included.
85056A 2.4 mm 0.045 - 50 Contains open and short circuits, fixed and sliding terminations and in-series adapters.
85056D 2.4 mm 0.045 - 50 Economy kit. Contains open and short circuits, fixed terminations and in-series
adapters. Gauges not included.
85056K 2.92/2.4 mm 0.045 - 50 Contains 2.4 mm open and short circuits, fixed loads and 2.92 mm adapters.
85059A 1 mm 0.045 - 110 Broadband coaxial precision calibration kit consists of 1 mm shorts, opens, fixed
loads and in-series adapters. It also includes offset-shorts covering 50 to 110 GHz.
Gauges not included.
11904S 2.92 mm 0.045 - 40 Must be used with Agilent 85056A/D 2.4 mm calibration kit. Includes four 2.92 mm-to-
2.4 mm adapters. Gauges not included.
X11644A WR-90 8.2 - 12.4
P11644A WR-62 12.4 - 18
K11644A WR-42 18 - 26.5
R11644A WR-28 26.5 - 40
Q11644A WR-22 33 - 50
U11644A WR-19 40 - 60
V11644A WR-15 50 - 75
W11644A WR-10 75 - 110
Contains standards for TRL calibration. Includes precision waveguide
section, short circuit and fixed or sliding terminations. Gauges not included.
