Adcom GDV-870 - Manual (Page 26)

26
Ch
ap
te
r 4 - O
pe
ra
ti
on
s
GDV-870 Owner’s Manual
Basic DVD Playback
Follow these steps to play a DVD.
Playing a DVD
1 Before you begin:
• Power on the GDV-870.
• Power on your TV or display device.
• Power on your AV preamp.
• Select the input on your TV and/or AV pre-
amp corresponding to the GDV-870.
2 Open the disc tray.
• Press the Eject button on the remote control
(or front panel) to open the disc tray.
3 Load your disc.
• Insert the disc with the label side up.
• Press the Eject button again to close the disc
tray.
4 Play the disc.
• Most discs will begin playback automatically
when loaded. The disc type will appear in
the top left corner of the screen.
• If the disc does not play, press the Play but-
ton.
• If the DVD disc menu appears, use the Arrow
buttons to highlight the desired option, then
press Select.
5 Adjust the volume.
• Use the Volume +/- buttons to adjust the
volume level.
• Press the Mute button to temporarily mute
the audio.
6 Pause or Stop playback.
• Press the Pause button to freeze playback.
Press Play to resume.
• Press the Stop button once to stop and hold
playback at the current playback position.
Press Play to resume.
• Press the Stop button twice to stop and reset
the disc from the beginning.
7 Eject the disc.
• Press the Eject button to open the disc tray
and remove your disc.
8 Power off the player.
• Press the Power button to turn off the
player. You should always power off the
player after use.
clear
power
display
setup
PBC
HDMI
goto
program
rev
eject
prev
title menu
vol-
slow step
zoom
play
mute
select
pause
audio angle vid.off subtitle
stop
vol+
aspect
C
next f wd
repeat
p.scan on compnt off
video output dig audio out
A-B 1/all
1 2 3
4 5 6
7 8 9
+10 0
Power Eject
Select
Play
Volume
Pause
Arrows
Stop
Mute
