Hand-held Refractometer
The Ultimate Hand-Held Refractometer Unsurpassed
in Function, Operation, and Design
ALL NEW DESIGN
● Af ter sa mp lin g,t he prism can be cleanedw ithru nnin gw ate r.● ● S a m pl e s ize: 2-3 d ro p s●
● A u to m at ic Te mpe rature Com pe ns ati o n
● ● A ut om ati c S ample Distr ibu tio n●
Design Registration No.000379326-0001, 000379326-0002 (EU)
ZL 2005 3 0116403.4,5 (China), D111526 (Taiwan), D555, 549 (U.S.A.),
1255763, 1255764, 1255765, 1255766, 1255767 (Japan)
Patent Granted in countries around the world.
Efficiently using an analog unit depends on
how easily the measured value can be read.
With extensive research and the utilization
of quality optics, the result is a view of the
m e a s u r e m e n t s c a l e t h a t i s v e r y b r i g h t ,
creating a high contrast to see clearly where
the boundary intersects the memory lines of
the scale.
Visibility
Measuring sugar concentration,
concentration and Brix
Reasons to choose the MASTER
The concept of a washable hand-held analog
unit is exceptional. After measuring, you can
clean the refractometer with running water
under a faucet. The new structural-design
of these units allows them to be washed
whenever necessary.
Water Resistant
This new system allows the MASTER series
to have improved accuracy that outperforms
similar units. ATAGO has applied for a patent
on the design of the improved ATC system.
The MASTER series reads more accurately
than any comparable unit on the market.
Automatic Temperature Compensation (ATC)
The MASTER series design has a smooth and
easy-to-clean grip, eliminating the possibility
of food and other samples being trapped,
w h i c c o u l d r e s u l t i n c o n t a m i n a t i o n a n d
bacterial growth.
Hygienic Design
ATAGO has developed a spoon-shaped tip,
which makes applying the sample easy, and
helps the sample spread across the prism on
its own. This makes the instrument even more
user-friendly. (Patent Pending)
Automatic Sample Distribution (ASD)
The MASTER series has passed all water
resistance, dust resistance, and drop tests.
The only replacement part for the MASTER
series is the daylight plate. The instruments
do not utilize consumable parts or materials,
thus keeping the cost for replacement parts
to a minimum.
Durability
ATAGO has built a fi rm reputation for reliability
and quality during its 69 -year history. We are
a strong company that exports to over 154
countries with continued growth expectations.
ISO 9001 certifi ed, along with our integrated
sys tem for pr oducing a nd ma r keting our
products, based on the “Plan-Do-Check-Act”
cycle, is essential to the continued quality and
to the promoting of the ATAGO name.
Reputation for Quality
ATAGO has established a close network of
customers by providing excellent customer
s e r v i c e a n d s u p p o r t . W h e n a n ATA G O
instrument needs servicing, not only is each
customer treated with respect, but they are
also provided with detailed methods and user-
specifi c suggestions on sampling and taking
measurements, based on individual needs.
Repair and Service
Small Volume Daylight
Plate With Hinge Pin
For metal body model
Parts.No. RE-2311 -58 M
For plastic body model
Parts.No. RE-2391 -50 M
Extractor
Parts.No. RE-29401
Sucrose solution
(for Brix confirmation)
Parts.No. RE-110010 10 % Sucrose
Parts.No. RE-110030 30 % Sucrose
Parts.No. RE-110050 50 % Sucrose
Light refraction
Water Concentrated suger water
Light
refraction
When a straw is placed in a glass of water, the straw appears bent. When a straw is placed in a glass
with water containing dissolved sugar, the straw should appear even more bent. This phenomenon is
known as the principle of
light refraction . Refractometers are measuring instruments which put this phenomenon of light refraction to practical use. They are based on the principle that as the density of
a substance increases (e.g. when sugar is dissolved in water), its refractive index (how much the straw
appears bent) rises proportionally.
Sugar concentration
Fruit juices, jam and honey contain many elements
but the main ingredient is sugar. Sugar concentration
can be indicated in Brix (%). Brix is a measurement
scale based on sucrose in distilled water. For example,
10 grams of cane sugar in 90 grams of distilled water
equates to a 10 % Brix solution. Since the majority of
dissolved solids in fruit juice are sugar, the Brix scale
is ideal to measure these samples.
Concentration
S o u p s , s t e w s , a n d s a u c e s
contain salts, acids, ex tr acts
as well as sugar. The total of all
these dissolved ingredients in
water is called “Soluble Solids”.
The concentration is generally
indicated in percentage.
Brix
A r ef r ac to mete r me a s u r e s t he co nc e nt r atio n pe r ce nt ag e a n d
displays this as a value of Brix(%). When measuring samples such as
fruit juice or jam, which consist almost entirely of sugar, the Brix(%)
should almost equal the actual sugar concentration. With samples
such as soup or sauce containing many other ingredients, the
Brix(%) is indicating the total concentration percentage. Generally
the measurements obtained are not indicated specifi cally as
“SUGAR
CONCENTRATION ” or “CONCENTRATION ”, but simply Brix(%) ”.
Convenient
storage box.
Bits of Knowledge
MASTER series awarded
2006 “Good Design Award”
2007 “The Invention Prize”
2007 “Japan Patent Offi ce Commissioner Encouragement Prize”
2009 “The Commendation for Science and Technology award” Fruit and vegetable juice/
Leaf juice/Stem juice/
Root juice
▲
Agriculture
Fire extinguishing solution/
Soluble cutting oil
▲
Machine Tools
Condiment/Various sauces/
Soy sauce/Jam/
Soybean milk/Honey/Oil
▲
Food
Brine/Snow-melting agent/
Medicine/Chemical/Cosmetics/
Cleaning solution
▲
Chemicals and medicine
Sodium chloride solution/
sea water
▲
Salinity
Fruit juice/Soft drink/
Carbonated beverage
▲
Drink
Urine/Serum
▲
Clinical
Chinese noodle soup/
Various soup/Various sauces
▲
Cooking
Application ─ Measuring sugar concentration,
concentration, Brix and Refractive Index ─ Brix of Various Samples ─ Refractive index and
Brix of various types of samples ─
Optional
※Pleas use as a guide when you select a refractometer
