Page 8
4
TTi
™
Colorimeter Series Quick-Start Guide
GUIDE TO PARTS, OPERATING CONTROLS,
AND MAIN MENU
Review the following illustrations to become familiar
with parts, operating controls, and Main Menu options.
Top View
1.
Power Button
2.
Main Menu Button
3.
Backlight Button
4.
Enter Button, to enter
the highlighted function
5.
Scroll Up Arrow
6.
Scroll Down Arrow
7.
Scroll Right Arrow
8.
Scroll Left Arrow
9.
Liquid Crystal Display
10.
USB Port Cover
11.
Model Number
12.
Sample Cell
Compartment
(shown open)
13.
Sample Cell
Compartment Cover
Top View
1
5
7
12
11
13
6
3
4
8
9
10
2
