3.1.3 Last Available Relay
The 1816 is capable of working with up to 1200 telephones, i.e. it can select one of up to 1200
system relays that are numbered 0000 through 1199. You must program into the system the last
relay number that is available. Determine how many relay boards are connected to the system, then
using the chart below, select the last available relay. For example, if your system uses 55 relay
boards, the last relay available is 0671.
Factory Default = 0011
1. Take the doorman telephone off hook.
2. Press *07 and enter the four-digit MASTER CODE _ _ _ _ (beep).
3. Enter the four-digit last available relay number _ _ _ _ then press * (beep).
4. Hang up the doorman telephone to end the programming session.
Board
Number
1 st
Relay
Last
Relay
Board
Number
1 st
Relay
Last
Relay
Board
Number
1 st
Relay
Last
Relay
Board
Number
1 st
Relay
Last
Relay
0 0000 0011 0300 0311 0600 0611 0900 0911 25 50 75
1 0012 0023 26 0312 0323 51 0612 0623 76 0912 0923
2 0024 0035 27 0324 0335 52 0624 0635 77 0924 0935
3 0036 0047 28 0336 0347 53 0636 0647 78 0936 0947
4 0048 0059 29 0348 0359 54 0648 0659 79 0948 0959
5 0060 0071 30 0360 0371 55 0660 0671 80 0960 0971
6 0072 0083 31 0372 0383 56 0672 0683 81 0972 0983
7 0084 0095 32 0384 0395 57 0684 0695 82 0984 0995
8 0096 0107 33 0396 0407 58 0696 0707 83 0996 1007
9 0108 0119 34 0408 0419 59 0708 0719 84 1008 1019
10 0120 0131 35 0420 0431 60 0720 0731 85 1020 1031
11 0132 0143 36 0432 0443 61 0732 0743 86 1032 1043
12 0144 0155 37 0444 0455 62 0744 0755 87 1044 1055
13 0156 0167 38 0456 0467 63 0756 0767 88 1056 1067
14 0168 0179 39 0468 0479 64 0768 0779 89 1068 1079
15 0180 0191 40 0480 0491 65 0780 0791 90 1080 1091
16 0192 0203 41 0492 0503 66 0792 0803 91 1092 1103
17 0204 0215 42 0504 0515 67 0804 0815 92 1104 1115
18 0216 0227 43 0516 0527 68 0816 0827 93 1116 1127
19 0228 0239 44 0528 0539 69 0828 0839 94 1128 1139
20 0240 0251 45 0540 0551 70 0840 0851 95 1140 1151
21 0252 0263 46 0552 0563 71 0852 0863 96 1152 1163
22 0264 0275 47 0564 0575 72 0864 0875 97 1164 1175
23 0276 0287 48 0576 0587 73 0876 0887 98 1176 1187
24 0288 0299 49 0588 0599 74 0888 0899 99 1188 1199
