Diamond Products CC100 User Manual
Page 5

40
SCALE 1 : 4
39
DETAIL C
4
6
SCALE 1 : 4
DETAIL D
5
DESCRIPTION
1
6041113: CC100 FRAME ASSEMBLY
6041033
1
Frame Base Weldment
2
6041047
1
Leg Weldment
3
2900948
2
Retainer, 1/2"
4
2501040
2
Spring, 3/4 x 2-3/4", Extension
5
6041048
1
Foot Pedal Weldment
6
2900139
3
Cap Screw, Hex Hd., 1/2-13 x 1-
3/4"
7
2900037
2
Hex Nut, 1/2-13
8
6041049
1
Axle Shaft Weldment
9
2900295
2
Flat Washer, 1" SAE
10
2501039
2
Wheel, 12 x 3 x 1"
11
2500009
2
Set Collar, 1" ID
12
6041026
1
Splashguard, 7 x 11"
13
2900022
15
Flat Washer, 5/16" SAE
14
2900138
9
Cap Screw, Hex Hd., 5/16-18 x
1"
15
6041138
1
Flanged Hub W/ 1/8 Grease Port
16
3200179
1
Pipe Nipple, 1/8" NPT x 3"
17
3200388
1
1/8" Pipe Coupling
18
2900062
1
Grease Fitting, 1/8" NPT
19
2900058
4
Flat Washer, 1/2" SAE
20
2900949
4
Lug Nut, 1/2-20
21
6041146
1
CC100 Shaft/Coupling Assy.
22
6041056
2
Handle Support
23
6041063
1
Dust Port Bracket
24
2900014
8
Flat Washer, 3/8" SAE
25
2900596
4
Cap Screw, Hex Hd., 3/8-16 x 2-
1/2"
26
2900018
4
Lock Nut, 3/8-16 Nylon
ITEM PART NO. QTY.
ITEM PART NO. QTY.
DESCRIPTION
27
2503177
1
Hose Reducer, 2.0"-1.5" ID
28
3200095
1
Hose Clamp #32
29
6041023
1
Handle Weldment
30
2900257
2
Lock Pin, T Handle, 3/8"
31
2900053
4
Rivet, 3/32" Dia.
32
3200008
2
Close Nipple, 1/2" NPT
33
3200022
1
Fitting, 1/2" F. Pipe to 3/4" F.
Garden
34
3200027
1
Water Valve
35
3200155
1
Fitting, 1/2" M. Pipe to 3/4" M.
Garden
36
6040299
1
Water Hose Assembly
37
6040595
1
Dust Hose, 2" ID x 27", PVC
38
2800278
2
Wire Tie, 14"
39
2900947
2
Cap Screw, Soc. Hd., 5/16-18 x
2"
40
2900141
2
Hex Nut, 5/16-18
41
6041022
1
Weight Box
42
6041027
1
Splash Guard, 6-1/2 x 32"
43
6041038
3
Guard Clasp, 4.275"
44
6041039
1
Guard Clasp, 7.75"
45
6041052
1
Guard Clasp, 7.75"
46
2900217
6
Cap Screw, Hex Hd., 5/16-18 x
1-1/4"
47
2501047
1
Weight
48
1800001
2
Warning Label
49
1800506
2
Core Cut Decal
50
1800504
1
Label, Grease Often
51
1800169
1
Serial Number Plate, US
1
5
2
SCALE 1 : 4
DETAIL B
38
5
