4646207 CB35XL PANEL ASSEMBLY
ITEM PART
NO.
QTY.
DESCRIPTION
1
4646141
1
Instrument Panel
2
2900022
8
Flat Washer, 5/16" SAE
3
2900031
6
Lock Washer, 5/16" Split
4
2900138
6
Cap Screw, Hex Hd., 5/16-18 x 1"
5
4645054
1
Manifold, SAE O-Ring, 5/8 & 3/4" Ports
6
4646101
1
Manifold, 3/4 NPT
7
2900009
20 Flat Washer, 1/4" SAE
8
2900667
4
Cap Screw, Hex Hd., 1/4-20 x 3"
9
2901001
4
Cap Screw, Hex Hd., 1/4-20 x 2-1/2"
10
2900010
10 Lock Nut, 1/4-20 Nylon
11
3200479
1
Plug, 3/4" NPT Square Head
12
3200097
1
Adapter, 3/4" M. JIC to 3/4" M. Pipe
13
3200417
1
Elbow, 3/4" F. JIC to 3/4" M. JIC
14
3200082
2
5/8" MJIC TO 3/4" MPT
15
3200626
1
Adapter, 5/8" O-Ring to 1/4" M. JIC
16
3201241
1
Elbow, 1/4" M. JIC to 1/4" F. JIC
17
3202077
1
5/8 MJIC - 3/4" MOR, 90 Deg.
18
3202079
1
5/8" O-Ring - 5/8" MJIC
19
3200330
1
Adapter, 3/4" M. Pipe to 3/4" O-Ring
20
3201899
1
Adapter, 1/2" MPT to 3/4" O-Ring
21
3200105
1
Nipple, 1/2" Q.D.
22
3200101
1
Nipple, 3/4" Quick Disconnect
23
3200137
1
Hex Nipple, 3/4" NPT
24
3200383
1
Nipple, Hex, 3/4" MPT TO 1/2" MPT
25
3200100
1
Coupler, 3/4" Quick Disconnect
26
3200104
1
Coupler, 1/2" Q.D.
27
2400307
1
Heat Exchanger
28
2900303
2
Lock Nut, M8-1.25 Nylon Insert
29
3200400
2
Elbow, 3/4" O-Ring to 3/4" Male JIC
30
3202083
1
Valve, Flow Control, 16 GPM
31
3202061
3
Fitting, 5/8" MORB x 5/8" MJIC x 90 DEG
32
2900245
2
Cap Screw, Soc. Hd., 1/4-20 x 2-5/8"
33
3202413
1
Gauge, Hydraulic, 4000 PSI
34
2801367
1
E-Stop Switch
35
2801502
1
Tach/Hour Meter, W/#6 Screws
36
3201659
2
Fitting, 3/4" M. Pipe to 3/4" M. Garden
37
3200177
1
Fitting, 3/4" F. Garden Union Swivel
38
2500204
1
Plug, 1/2" Hole
39
2503749
1
Plug, 5/16" Hole (Tapered)
40
1800536
1
"Return" Decal
41
1800941
1
Decal, Hydraulic Power Supply
42
1800531
1
"Hyd. Pressure" Decal
43
1801907
1
Decal, Stop
44
1801852
1
Decal, CB35 Flow Control
45
1801366
1
Decal, Core Bore CB35
