Table of Contents
Description Page No.
1. CB21 Top Level Assembly……………………………………..…4-9
2. Hydraulic Schematic ………….……………………………………10
3. Hose Kit …………..…………………………………………………..11
4. Fuel Line Routing…………………………………………………….12
5. Gas Tank Assembly……………………………………………..….13
6. Electric Schematic ………………………………………..……..…14
7. Hydraulic Tank Assembly…………………………,,………….….16-17
5. Front Panel Assembly ……..……….…………………..……….18-19
6. Oil to Air Cooler Option……………………………,…….………..20-21
9. Reference Views ……………………………………………………23
10. General Safety Precautions ……………………………..……...24-25
11. Specifications & Description……………………………,………26-27
Hydraulic Fluid
Control Valve
Cooler and Radiator
Hoses
12. Operating Instructions……………………………………………27-28
Hose Connections
Engine
Fuel
Starting Procedure
Heating Cold Oil
Maintaining Oil Temperature
Shutting Down
13. Operating Driven Equipment……………………………….………28
14. Maintenance and Troubleshooting ………………………..…….29
15. Flow & Pressure Ratings, CB Power Packs…………..…………31
16. Warranty………………………….……………………….…Rear Cover
