Diamond Products CB18BV-XL User Manual
Page 15
4641103 CB18 XL PANEL ASSEMBLY
ITEM
PART NO.
QTY.
DESCRIPTION
1
4641062
1
Instrument Panel
2
4646102
1
Manifold, SAE O-Ring
3
4646101
1
Manifold, 3/4 NPT
4
2900009
22
Flat Washer, 1/4" SAE
5
2901001
8
Cap Screw, Hex Hd., 1/4-20 x 2-1/2"
6
2900010
10
Lock Nut, 1/4-20 Nylon
7
3200479
3
Plug, 3/4" NPT Square Head
8
3201434
1
Plug, 1/2" SAE O-Ring Hex
9
3200367
1
Elbow, 1/2" O-Ring to 1/2" Male JIC 45 Deg.
10
3201291
1
Adapter, 1/2"M.O-Ring to 1/4" MJIC
11
3201241
1
Elbow, 1/4" M. JIC to 1/4" F. JIC
12
3200444
1
3/4" MPT to 1/2" MJIC, 45 Deg.
13
3200097
1
Adapter, 3/4" M. JIC to 3/4" M. Pipe
14
3201306
1
#12 MOR PLug (3/4" O-Ring)
15
3200371
1
Adaptor, 1/2" MPT to 1/2" O-Ring
16
3200105
1
Nipple, 1/2" Q.D.
17
3200383
1
Nipple, Hex, 3/4" MPT TO 1/2" MPT
18
3200104
1
Coupler, 1/2" Q.D.
19
3201654
1
Valve, Flow Control
20
3200287
3
Adapter, 5/8" O-Ring to 1/2" M. JIC
21
2900245
2
Cap Screw, Soc. Hd., 1/4-20 x 2-5/8"
22
3200250
1
Gauge, Hydraulic, 3000 PSI
23
3200131
1
1/4" FPT, 45 Deg.
24
2801367
1
E-Stop Switch
25
2801502
1
Tach/Hour Meter, W/#6 Screws
26
2800144
1
Relay, 50 Amp, 12 V, SPDT
27
2900016
2
Flat Washer, #10 USS
28
2900159
1
Machine Screw, Rd. Hd., #10-24 x 5/8"
29
2900017
1
Lock Nut, #10-24 Nylon
30
2800481
1
Fuse Holder
31
2803014
1
Fuse, 15 Amp, Slo Blow
32
2900024
1
Lock Washer, 1/4" Split
33
2900008
1
Cap Screw, Hex Hd., 1/4-20 x 1"
34
2900125
1
Hex Nut, 1/4"-20
35
1800536
1
"Return" Decal
36
1800941
1
Decal, Hydraulic Power Supply
37
1800531
1
"Hyd. Pressure" Decal
38
1801907
1
Decal, Stop
39
1801848
1
Decal, CB18 Flow Control
40
1801692
1
Decal, Core Bore CB18
41
1800169
1
Serial Number Plate, US
42
2900053
2
Rivet, 3/32" Dia.
43
2900022
6
Flat Washer, 5/16" SAE
44
2900031
6
Lock Washer, 5/16" Split
45
2900958
6
Cap Screw, Hex Hd., 5/16-18 x 1/2"
15
