Diamond Products M-6 User Manual
Page 11
#4640115
M-6 Autofeed Quick Disconnect Carriage Assembly
ITEM
PART NO.
QTY.
DESCRIPTION
1
4640050
1
Cover Plate
2
2900116
4
Cap Screw, Soc. Hd., #10-24 x 3/4"
3
2500249
1
Sprocket, #35,10 Tooth
4
4640092
1
Spur Gear Assembly, Modified, M-6
5
4640049
1
Chain Guard for Hyd. M-6
6
2900103
2
Cap Screw, Soc. Hd., 5/16-18 x 1"
7
2900031
4
Lock Washer, 5/16" Split
8
2900506
3
Cap Screw, Flat Head, 1/4-28 x 3/4"
9
4640048
1
Motor Mount (OMM Hyd.)
10
2600083
1
Hydraulic Motor, Danfoss OMM32
11
3200271
1
Elbow, 3/8" O-Ring to 3/8" M. JIC
12
3200272
1
Long Elbow, 3/8" O-Ring to 3/8" M. JIC
13
2900010
6
Lock Nut, 1/4-20 Nylon
14
3200263
2
Adapter, 3/8" O-Ring to 3/8" M. JIC
15
3200138
2
Adapter, 1" O-Ring to 3/4" F. Pipe
16
3200036
2
Elbow, 3/4" Male Pipe
17
3200101
1
Nipple, 3/4" Quick Disconnect
18
4640093
3
Threaded Rod, 1/4-20 x 4"
19
3200499
1
Manifold, M-6 Autofeed
20
3200100
1
Coupler, 3/4" Quick Disconnect
21
3200392
2
Hose Assembly, 3/8" x 14" Lg. HP
22
4641023
1
Handle Housing, M-6
23
4641016
4
Handle, Spoke, M-2
24
2900124
1
Cap Screw, Soc. Hd., 3/8-16 x 1-3/4"
25
6011089
1
Key, 1/4" Sq. x 1" Long
26
2900912
2
Cap Screw, Soc. Hd., 5/16-18 x 3/4"
27
4640053
1
Sprocket, Hydraulic, M-6
28
6020018
1
Chain, #35,68 Pitch Length
29
2500020
1
#35 Offset Link
30
2900247
4
Cap Screw, Soc. Hd., 1/4-20 x 3/4"
31
4640009
3
Adjustable Roller Assembly, M-6
32
4640033
8
Side Roller Assembly, M-6 Only
33
4640013
3
Non-Adjustable Roller Assembly, M-6
34
4640098
1
M-6 Left Side Carriage Plate Ass'y
35
4640099
1
M-6 Right Side Carriage Plate Ass'y
36
4640015
1
Pinion Gear Assembly, M-6
37
4699997
1
M6 QD Motor Mount Assembly
38
4640024
1
Cover Plate, M-6, Power Raise & Lower
39
2900416
2
Tap Screw, Hex Hd., 1/4-20 X 1-1/2"
11
