Blade Speed Conversion Charts
WARNING:
Blade Size
Max. Depth
of Cut
No Load RPM Sheave Size No Load RPM Sheave Size
14" 3,000 3.65" 3,000 3.65" 4-5/8"
20" 2,475 4.12" 2,800 3.65" 7-5/8"
26" 1,900 4.12" 2,500 3.12" 10-5/8"
30" 1,650 4.75" 2,500 3.12" 11-3/4"
36" 1,400 4.75" 2,150 3.12" 14-3/4"
WARNING:
14" 20" 26" 30" 36"
6010600 6010602 6010604 6010606 6010608
6011009
(3.65")
6011009
(3.65")
6012005
(3.12")
6012005
(3.12")
6012005
(3.12")
6011009
(3.65")
6011010
(4.12")
6011010
(4.12")
6012052
(4.75")
6012052
(4.75")
6010036
(4.5")
6010036
(4.5")
6010036
(4.5")
6010038
(6")
6010038
(6")
6010037
(4.5")
6010037
(4.5")
6010037
(4.5")
6010039
(6")
6010039
(6")
Bottom Set Bottom Set Bottom Set Top Set Top Set
When changing blade size, use chart shown below for selecting items that must be changed.
Outer Flange
(Flange Size)
Skid Plate
Mounting Holes
Do not exceed blade speed (RPM) shown for each blade size.
Excessive blade speed could result in blade breakage and serious personal injury!
Blade Shaft Engine
Engine Sheave, 1-3/4" Bore
(Sheave Size)
Blade Shaft Sheave, 1-3/4" Bore
(Sheave Size)
Inner Flanges (2)
(Flange Size)
Model CC3728
Blade Guard Assembly
