Blade / Engine Speed (RPM) Chart
Model CC3765 Concrete Saw
_____________________________________________________
WARNING:
Do not exceed Bladeshaft speed (RPM) shown for each blade size. Excessive Blade
Speed could result in blade breakage and serious personal injury.
Blade Size
Max Depth
of Cut
Blade Size Bladeshaft Engine
Governor
Setting
14” 4-5/8” No Load RPM Sheave Size No Load RPM Sheave Size
20” 7-5/8” 14” 2,900 4.12” 3,000 4.00” 10
26” 10-5/8” 20” 2,450 4.50” 2,750 4.00” 9
30” 11-3/4” 26” 1,950 4.50” 2,200 4.00” 6
36” 14-3/4” 30” 1,650 5.30” 2,200 4.00” 6
36” 1,400 5.30” 1,850 4.00” 4
CAUTION:
When changing blade size, use chart shown below for selecting items that must be changed.
Model CC3765 14” 20” 26” 30” 36”
Blade Guard Assembly 6010070 6010072 6010074 6010076 6010260
Engine Sheave, 1-3/4” Bore
(Sheave Size) 6010147
(4.12”)
6010149
(4.50”)
6010149
(4.50”)
6012053
(5.30”)
6012053
(5.30”)
Engine Belts (8)
(Belt Size) 2500438
(3VX530)
2500438
(3VX530)
2500438
(3VX530)
2500188
(3VX560)
2500188
(3VX560)
Inner Flanges
(Flange Size) 6010036
(4.50”)
6010036
(4.50”)
6010036
(4.50”)
6010038
(6.25”)
6010038
(6.25”)
Outer Flange
(Flange Size) 6010037
(4.50”)
6010037
(4.50”)
6010037
(4.50”)
6010039
(6.25”)
6010039
(6.25”)
Skid Plate Mounting Holes Bottom Set Bottom Set Bottom Set Top Set Top Set
Engine Base Mounting Holes Front Set Front Set Front Set Rear Set Rear Set
Options Available:
#6011032 Water Pump Kit - includes 12 Volt Pump, Toggle Switch, Hose and Fittings.
#6010112 Spotlight Kit - includes 12 Volt Light, Mounting Bar and Bracket, Lock Knobs, Toggle Switch.
#2700143 Vertical Muffler Kit - includes Muffler, Clamp and Rain Cap.
#6010179 Free Wheeling Clutch Kit - includes Clutch Sprocket and Hub, Engage/Disengage Lever, Linkage.
#6047932 Water Safety Switch Kit – includes Safety Shut-off Switch and Toggle Switch.
#6010226 Bladeshaft Tachometer Kit - includes Tach/Hour Meter, Magnetic Sensor, Gear, Wiring Harness.
#6010227 Lowering Speed Metering Valve Kit - includes Metering Valve, Check Valve, Hydraulic Hose & Fittings.
#6011170 Magnetic Spotlight Kit – includes 12 Volt Light with Magnetic Base, Power Outlet, Toggle Switch.
#6012071/2 Catalytic Converter Kit – includes Catalytic Muffler, Air Pump, Belt, Hoses, Pulley, Hardware.
#6010249 Extended Bladeshaft Kit (3/4” to 1-1/2”) – includes 5” Extended Outer Flange, Bolt, 20” Extra Wide Blade Guard.
#6010229 Extended Bladeshaft Kit (1-1/2” to 2-1/4”) – includes Shaft Extension, 5” Outer Flange, Nut, 20” Extra Wide Blade Guard.
#6010181 Oil Cooler Kit – includes Cooler, Oil Filter, Adapters, Hose and Fittings.
#6010185 Side Plunge Kit – includes Bladeshaft, 8” Flanges, and 20” Extra Wide Blade Guard.
