Diamond Products CC3700 - Manual (Page 11)

__________________________________
CC3700 Parts List
Drawing lll
Engine Group
_______________________________
Diagram
Number
Part
No.
Qty.
Req.
Description Diagram
Number
Part
No.
Qty.
Req.
Description
1 2600191 1 Engine, 65 Hp Wisconsin Model V465D1 14 6010177 1 Oil Drain Hose Assembly (65HP)
(Includes #2 and #3) (Includes #15 - #18)
2600120 1 Engine, 37 Hp Wisconsin Model VG4D2 6012015 1 Oil Drain Hose Assembly (37HP)
(Includes #2 and #3) (Includes #15 - #18)
2 2700179 1 Muffler, Horizontal with Clamp (65HP) 15 3200162 1 Fitting, 3/4" Male Pipe to 1/2" Push Lock (65HP)
2700189 1 Muffler, Horizontal with Clamp (37HP) 3200172 1 Fitting, 1/2" Male Pipe to 1/2" Push Lock (37HP)
2700600 1 Muffler, Vertical (65HP) 16 6010245 1 Oil Drain Hose, 13" Long (65HP)
2700258 1 Muffler, Vertical (37HP) 6012031 1 Oil Drain Hose, 12" Long (37HP)
3 3200051 1 Pipe Nipple, 2" NPT (65HP) 17 3200163 1 Fitting, 1/2" Female Pipe to 1/2" Push Lock
3200171 1 Pipe Nipple, 1-1/2" NPT (37HP) 18 3200160 1 Plug, 1/2" NPT
4 2900195 4 Capscrew, Hex Hd., 5/8"-11 x 3" 19 2800073 1 Battery Cable, Positive (Red)
5 2900002 4 Flat Washer, 5/8" SAE 20 6010194 1 Idler Assembly, 65HP (Includes #21 - #29)
6 2900135 4 Lock Nut, 5/8"-11 Nylon 6012032 1 Idler Assembly, 37HP (Includes #21 - #29)
7 6010161 1 Bevel End Key, 1/2" Square (65HP) 21 6048218 1 Idler Arm (65HP)
6011172 1 Bevel End Key, 3/8" Square (37HP) 6012013 1 Idler Arm (37HP)
8 2900142 4 Setscrew, Soc. Hd., 5/16"-18 x 3/8" 22 2500074 1 Idler Pulley
9 2900418 10 Setscrew, Soc. Hd., 5/16"-18 x 5/8" 23 2900013 1 Capscrew, Hex Hd., 3/8"-16 x 1-1/4"
10 6010041 1 Accessory Drive Pulley, 2" Bore (65HP) 24 2900006 2 Lock Washer, 3/8" Split
6012006 1 Accessory Drive Pulley, 1-3/4" Bore (37HP) 25 2900521 1 Tap Bolt, Hex Hd., 3/8"-16 x 2-1/2" (65HP)
11 6010151 1 Sheave, 4.00-8 Groove x 2" Bore (65HP) 2900520 1 Tap Bolt, Hex Hd., 3/8"-16 x 3" (37HP)
6012027 1 Sheave, 4.12-7 Groove x 1-3/4" Bore 26 2900018 1 Lock Nut, 3/8"-16 Nylon
for 14" and 20" Blade Guards (37HP) 27 2900033 1 Hex Nut, 3/8"-16
6012026 1 Sheave, 3.65-7 Groove x 1-3/4" Bore 28 2500195 1 Idler Spring, 3/8" x 7-3/4"
for 26" - 36" Blade Guards (37HP) 29 2900055 1 Cotter Pin, 3/16" x 1"
12 2500438 8 V-Belt, 3VX530 for 14" - 26" Blade 30 6010050 1 Pointer Stop
Guards (65HP) 31 2900508 2 Capscrew, Hex Hd., 5/16"-18 x 1-1/2"
2500188 8 V-Belt, 3VX560 for 30" and 36" Blade 32 2900031 2 Lock Washer, 5/16" Split
Guards (65HP) 33 2900022 2 Flat Washer, 5/16" SAE
2501156 2 Banded Belt, 3VX530 - 4 Strand for 34 2500376 1 Vernier Throttle Cable
14" - 26" Blade Guards (65HP) 35 2500940 1 Throttle Cable Clamp
2500589 2 Banded Belt, 3VX560 - 4 Strand for 36 2900411 2 Tapscrew, Hex Washer Hd., #10 x 3/4"
30" - 36" Blade Guards (65HP) 37 3200095 1 Hose Clamp, #32
2500438 7 V-Belt, 3VX530 (37HP) 38 2500470 1 Air Intake Hose
13 6010147 1 Sheave, 4.12-8 Groove x 1-3/4" Bore 39 3200096 2 Hose Clamp, #40
for 14" Blade Guard (65HP) 40 2500180 1 Air Cleaner, Complete
6010149 1 Sheave, 4.50-8 Groove x 1-3/4" Bore 2500237 1 (Outer Primary Element)
for 20" and 26" Blade Guards (65HP) 2500238 1 (Inner Safety Element)
6012053 1 Sheave, 5.30-8 Groove with 1-3/4" QD 2500239 1 (Rubber Dust Ejector Boot, 2")
Bushing for 30" and 36" Blade Guards (65HP) 41 2500105 1 Pre-Cleaner with Clamp
2500390 1 (Sheave Only, 5.30-8 Groove) 2500493 1 (Clear Plastic Bowl Only)
2500176 1 (Bushing Only, 1-3/4" QD with Capscrews) 42 2500423 1 Restriction Indicator
6012026 1 Sheave, 3.65-7 Groove x 1-3/4" Bore 43 2500107 2 Mounting Strap, 5-1/4"
for 14" Blade Guard (37HP) 44 2900019 4 Capscrew, Hex Hd., 5/16"-18 x 3/4"
6012027 1 Sheave, 4.12-7 Groove x 1-3/4" Bore 45 2900039 4 Lock Nut, 5/16"-18 Nylon
for 20" and 26" Blade Guards (37HP) 46 2800386 1 Vacuum Switch
6012033 1 Sheave, 4.75-7 Groove x 1-3/4" Bore
for 30" and 36" Blade Guards (37HP)
Note: Underlined part numbers apply to CC3737 saw only
