Diamond Products CC3700 User Manual
Page 25
_____________________________
Wiring Diagram
35Hp / 65Hp Wisconsin Engine
(After 9-1-2000)
_____________________________
Diagram
Number
Part
No.
Qty.
Req.
Description
Diagram
Number
Part
No.
Qty.
Req.
Description
1
2800390
1
Engine Harness (Includes #35)
28
2800271
1
Volt Meter
2
2800391
1
Control Panel Harness (Includes #36)
29
2800064
1
Hour Meter
3
2800392
1
Relay Harness
30
2800168
1
Optional Tach/Hour Meter
4
2800393
1
Hydraulic Pump Harness
2800267
1
Light Bulb, Wedge Base
5
2800073
1
Battery Cable, Positive (Red)
31
2800169
1
Optional Magnetic Sensor (Includes #33)
6
2800072
1
Battery Cable, Negative (Black)
32
2800397
1
Optional Tach Sensor Harness
7
2800095
1
Solenoid Cable, Positive (Red)
(Includes #33 & #34)
8
2800182
1
Ground Cable, Negative (Black)
33
2800145
2
Optional Connector, 2 Wire Shroud
9
2700208
1
Battery, 12 Volt
2800114
4
Male Terminal, 14/16 Gage Wire
10
2600070
1
Hydraulic Pump Unit (Includes #11 and #12)
2800174
4
Cable Seal, Gray
11
2700169
1
Solenoid, Motor
34
2800146
2
Optional Connector, 2 Wire Tower
12
2700243
1
Valve Coil
2800115
4
Female Terminal, 14/16 Gage Wire
2700244
1
Valve Stem
2800174
4
Cable Seal, Gray
13
2800372
1
Pushbutton Switch, Raise
35
2800110
1
Connector, 6 Wire Shroud
14
2800373
1
Pushbutton Switch, Lower
2800114
4
Male Terminal, 14/16 Gage Wire
15
2700205
1
Ignition Coil
2800112
2
Male Terminal, 12 Gage Wire
16
2701474
1
Distributor for 35HP Engine
2800174
4
Cable Seal, Gray
2701475
1
Distributor for 65HP Engine
2800175
2
Cable Seal, Blue
17
2700299
1
High Temperature Safety Switch
36
2800111
1
Connector, 6 Wire Tower
18
2701634
1
Flywheel Alternator, 30 Amp
2800115
4
Female Terminal, 14/16 Gage Wire
19
2701023
1
Rectifier/Regulator Module
2800113
2
Female Terminal, 12 Gage Wire
20
2700247
1
Starting Motor (Includes #21)
2800174
4
Cable Seal, Gray
21
2700282
1
Solenoid Switch
2800175
2
Cable Seal, Blue
22
2800386
1
Vacuum Switch
37
2800062
3
Optional Toggle Switch
23
2500220
1
Ignition Switch
2800063
3
Switch Boot
24
2800387
1
Circuit Breaker, 25 Amp
38
2800060
1
Optional Water Pressure Safety Switch
2800364
1
Circuit Breaker Boot, Red
39
2500194
1
Optional Spot Light, 12 Volt
25
2800144
1
Relay
40
2501087
1
Optional Magnetic Base Light, 12 Volt
2800263
1
Relay Connector
41
2800374
1
Optional Power Outlet, 12 Volt
2800264
4
Wire Terminal, 1/4" Push-on
2800375
1
Outlet Cap
26
2800213
1
Emergency Stop Button
42
2600200
1
Optional Water Pump, Diaphragm
2800229
1
Contact Block N.C.
43
2701030
1
Anti-Diesel Solenoid Valve
27
2800388
1
Fuse Panel, 6 Circuit
for 65HP Engine Only
2800389
6
Fuse, 10 Amp Red ATO/ATC
