Diamond Products CC1800XL (Hydraulic) User Manual
Page 33
2800881
INCLUDES
2700889
Starter Box Assembly, 10 HP, 3-Phase, 460V #6048306
ITEM
PART NO. QTY.
DESCRIPTION
1
6040300D
1
Starter Box Base
2
6010844
1
Electric Box Cover, 3 Hole
3
2800315
2
Grounding Lug
4
2701414
4
Fastener, Electrical Box Top
5
6040301C
1
Starter Box, Back Panel
6
2800881
1
Starter, 380-480 Volt
7
2800335
2
Auxiliary Contact
8
2700889
1
Coil, 380-480V
9
2900707
2
Machine Screw, Pan Hd., #10-32 x 1/4"
10
2900708
1
Machine Screw, Rd. Hd., #10-32 x 1/2"
11
2900676
4
Machine Screw, Pan Hd., M4 x 8mm
12
2800252
1
Amp Meter, 0-20 AC
13
2800085
1
Transformer, 115V
14
2701457
3
Heater, # E57
15
2900092
2
Lock Washer, #6 Split
16
2900090
2
Machine Screw, Rd. Hd., #6-32 x 1/2"
17
2900091
2
Hex Nut, #6-32
18
2802052
1
Connector, 3/4" Cord 90 Deg, Nylon
19
2801304
1
Lock Nut, 3/4"
20
6011305
1
Start Pushbutton Assembly
2701391
1
Cap, Black Flush
2701392
1
Contact Block (N.O.)
2800222
1
Clear Protective Boot
2701390
1
Pushbutton Operation Body
21
2801367
1
E-Stop Switch
22
6040423
1
Cable Assy., 10 Ga., 4 Wire x 54"
23
2800695
1
Cord Grip, 5/8-3/4", 90 Deg.
24
2800193
1
Lock Nut, 1"
25
1800811
1
Voltage Label, 460V
33
