Page 5
5801500 CC1507E Basement Saw Assembly Parts List
ITEM
PART NO.
QTY.
DESCRIPTION
1
6075134
1
Frame Weldment CC1507E
2
6075184
1
Blade Shaft Assembly CC1507E
3
6075180
1
Rear Axle Assembly CC1507E
4
6048184
1
Front Axle Assembly
5
6048183
1
Screw Feed Assembly
6
2400138
1
Indexing Plunger 1/2-13
7
6048182
1
Handle Bar Assembly
8
6075181
1
Belt Guard Assembly CC1507E
9
6075182
1
Water Hose Assembly
10
6075183
1
Power Supply Assembly CC1507E
11
2900596
2
Cap Screw, Hex Hd., 3/8-16 x 2-1/2"
12
2900014
3
Flat Washer, 3/8" SAE
13
6048908
1
Tapered Guard Mount
14
2900235
2
Cap Screw, Flat Hd., 3/8-16 x 1"
15
6048080
1
Pointer Assembly
16
6048904
1
20" Blade Guard (Slip-On Style)
17
6075139
1
7.5HP Electric Motor Assembly CC1507E
18
2502126
1
Tensioner K99
19
2900473
1
Flat Washer, 3/8" USS
20
2903030
1
Cap Screw, Hex Hd., 3/8-16 x 3-1/4"
21
2900006
1
Lock Washer, 3/8" Split
22
2900033
1
Hex Nut, 3/8-16
23
2500256
2
Wrench, 1-1/16" Open End (27MM)
24
6075136
1
Hub, Shaft Guard
25
1800001
1
Warning Label
26
1800352
1
Core Cut Saw Decal
27
1801450
1
Operating Label CC1507E
28
2500035
3
V-Belt, 3VX335
5
