Technical Specifications
© 2014 Multi Channel Systems MCS GmbH
MEAs for MEA2100-120-Systems
Temperature compatibility
Dimension (W x D x H)
Base material
Contact pad
Track material
Electrode diameter
Interelectrode distance
Electrode height
Electrode type
Isolation type
Electrode impedance
Electrode layout grid
Number of recording electrodes
Number of reference electrodes
Ring
120MEA:
120MEA200/30iR-Ti
120MEA100/30iR-ITO
10 °C – 50 °C
49 x 49 x 1 mm
Glass
Ti (Titanium) or ITO (Indium tin oxide)
Ti (Titanium) or ITO (Indium tin oxide)
30 µm
100 or 200 µm
Planar
TiN electrodes (Titanium nitride)
Silicon nitride 500 nm (PEVCD)
30 - 50 kΩ
12 x 12
120 electrodes
4 internal reference electrodes (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
Perforated 120MEA:
120pMEA200/30iR-Ti
10 °C – 50 °C
49 x 49 x 1 mm
Glass
TiAu (Titan, Gold)
TiAuTi (Titan, Gold, Titan)
30 µm
200 µm
Planar
TiN electrodes (Titanium nitride)
Silicon nitride 500 nm (PEVCD)
30 - 50 kΩ
12 x 12
120 electrodes
4 internal reference electrodes (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
