Technical Specifications
© 2014 Multi Channel Systems MCS GmbH
MEAs for MEA2100-(2x)60-Systems and MEA1060 Amplifiers
Temperature compatibility
Dimension (W x D x H)
Base material
Contact pad
Track material
Electrode diameter
Interelectrode distance
Electrode height
Electrode type
Isolation type
Electrode impedance
Electrode layout grid
Num. of record. electrodes
Num. of ref. electrodes
Ring
Thin MEA:
60ThinMEA30/10iR-ITO
60ThinMEA200/30iR-ITO
60ThinMEA100/10iR-ITO
0 °C – 125 °C
49 x 49 x 1 mm
Glass part 180 µm
Glass on ceramic base
Indium tin oxide (ITO)
Indium tin oxide (ITO)
10 µm and 30 μm
30 µm or 200 μm
Planar
Titanium nitride (TiN)
Silicon nitride (SiN)
500 nm (PECVD)
30 – 50 kΩ for 30 µm
electrodes
250 – 400 kΩ for 10 µm
electrodes
8 x 8. ThinMEA100/10iR
ThinMEA200/30iR
2 x (5 x 6):
ThinMEA30/10iR
500 µm between fields
59 electrodes
1 internal reference
electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
EcoMEA:
60EcoMEA
0 °C – 125 °C
49 x 49 x 1 mm
PCB (prin. circuit board)
Gold (Au)
Gold (Au)
100 μm
700 μm
Planar
Gold (Au)
PCB (printed circuit board)
~ 30 kΩ
8 x 8
59 electrodes
1 internal reference
electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
EcoMEA-Glass:
60EcoMEA-Glass
0 °C – 125 °C
49 x 49 x 1 mm
Glass
Gold (Au)
Gold (Au)
100 μm
700 μm
Planar
Gold (Au)
SU-8 (1-2 µm)
~ 30 kΩ
8 x 8
59 electrodes
1 internal reference
electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
Hexa MEA:
60HexaMEA-ITO
60HexaMEA-Ti
(60HexaMEA40/10iR-ITO)
0 °C – 125 °C
49 x 49 x 1 mm
Glass
ITO -or-Titanium nitride
ITO -or- Titanium
(Indium tin oxide (ITO))
10, 20, 30 μm (10 µm)
30, 60, 90 μm (40 µm)
Planar
Titanium nitride (TiN)
Silicon nitride (SiN)
500 nm (PECVD)
30 – 50 kΩ for 30 µm
electrodes
250 – 400 kΩ for
10 and 20 µm electrode
hexagonal
59 (with iR) 60 (without)
1 internal reference
electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
High Dense MEA:
60HD30/10iR-ITO
0 °C – 125 °C
49 x 49 x 1 mm
Glass
Indium tin oxide (ITO)
10 μm
30 μm
Planar
Titanium nitride (TiN)
Silicon nitride (SiN)
500 nm (PECVD)
250 - 400 kΩ
2 x (5 x 6)
500 or 150 μm between
the electrode fields
59 electrodes
1 internal reference
electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
