Multichannel Systems MEAs for MEA2100-(2x)60-Systems and MEA1060 Amplifiers User Manual
Page 3
Technical Specifications
© 2014 Multi Channel Systems MCS GmbH
MEAs for MEA2100-(2x)60-Systems and MEA1060 Amplifiers
Temperature compatibility
Dimension (W x D x H)
Base material
Contact pad
Track material
Electrode diameter
Interelectrode distance
Electrode height
Electrode type
Isolation type
Electrode impedance
Electrode layout grid
Num. of recording electrodes
Num. of reference electrodes
Ring
Perforated MEA:
60pMEA100/30iR-Ti
60pMEA200/30iR-Ti
10 °C – 50 °C
49 x 49 x 1 mm
Polyimide foil (2611)
with perforation
on ceramic or glass carrier
TiAu (Titan, Gold)
TiAuTi (Titan, Gold, Titan)
30 µm
200 µm: 8 x 8 grid
100 µm: 6 x 10 grid
Planar
TiN electrodes (Titanium nit.)
Polyimide foil (2610) isolator
30 - 50 kΩ
8 x 8: pMEA200/30iR-Ti
6 x 10: pMEA100/30iR-Ti
59 electrodes
1 internal reference electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
6 Well MEA:
6wellMEA200/30iR-Ti
0 °C – 125 °C
49 x 49 x 1 mm
Glass
Titanium nitride (TiN)
Titanium (Ti)
30 µm
200 µm
Planar
TiN electrodes
(Titanium nitride)
Silicon nitride (SiN)
500 nm (PECVD)
30 - 50 kΩ
3 x 3 in each of the 6 wells
54 electrodes
6 internal reference electrodes (iR),
one in each well
Without ring
Macrolon ring 6 wells, with round
chambers (rcr) or triangular
chambers (tcr)
Stimulation MEA:
60StimMEA200/30-Ti
0 °C – 125 °C
49 x 49 x 1 mm
Glass
Ti nitride (TiN)
Titanium (Ti)
30 µm
200 µm
Planar
TiN electrodes including
4 pairs of stimulation elect.
Silicon nitride (SiN)
500 nm (PECVD)
30 - 50 kΩ
8 x 8
60 electrodes
without internal reference electrode
Without ring
Glass ring
Quadrant MEA:
4QMEA1000iR-Ti
0 °C – 125 °C
49 x 49 x 1 mm
Glass
Titanium nitride (TiN)
Titanium (Ti)
30 µm
200, 500, 1000 µm
Planar
TiN electrodes
(Titanium nitride)
Silicon nitride (SiN)
500 nm (PECVD)
30 - 50 kΩ
4 quadrants (13 electrodes each)
and centre line (7 electrodes)
59 electrodes
1 internal reference electrode (iR)
Without ring
Glass ring
Plastic ring w/o thread
Plastic ring with thread
