B. Container. The container section is a middle part of a vacuum cleaner, used as a conta-

iner to collect dust and dirty water. This section is attached to engine’s set with clamps. A

container for a shampoo and clean water (washing liquid) is located under the water filter

container.

B1 – Container

B2 – Water filter tank

B3 – Water filter sponge

B4 – Water filter tube

B5 – Rubber gasket

B6 – Clamps

B7 – Locks sockets

B8 – Sucking inlet

C. Washing liquid container. Washing liquid container has a shampoo and clean water.

When the pump works, shampoo and water are taken from the tank. Liquid going from the

container through a hose is sprayed. Liquid container is situated between a water filter con-

tainer and a base with wheels.

C1 – Washing liquid container

C2 – Short washing hose

C3 – Short washing hose connector

C4 – Indicator of water level

D. A base with wheels

D1 – Base

D2 – Wheels

D3 – Lock

E. Hose. This section includes a sucking hose with a handle and sucking tubes. Sucking

attachment is connected with container’s set through putting the hose into sucking inlet.

Sucking tubes are jointed with each other and then connected to a handle. The handle has

washing liquid feeder and sucking power regulation. The hose can be put on engine’s set with

the use of hanger.

E1 – Element fixing a sucking hose

E2 – Element fixing a washing hose

E3 – Washing liquid hose

E4 – Clamps

E5 – Sucking hose

E6 – Liquid feeder lever

E7 – Sucking power regulation

E8 – Handle

E9 – Sucking tubes (2)

E10 – Hanger
